1. General description

The RT600 is a family of dual-core microcontrollers for embedded applications featuring

an Arm Cortex-M33 CPU combined with a Cadence Xtensa HiFi4 advanced Audio Digital

Signal Processor CPU. The Cortex-M33 includes two hardware coprocessors providing

enhanced performance for an array of complex algorithms. The family offers a rich set of

peripherals and very low power consumption.

The Arm Cortex-M33 is a next generation core based on the ARMv8-M architecture that

offers system enhancements, such as ARM TrustZone® security, single-cycle digital

signal processing, and a tightly-coupled coprocessor interface, combined with low power

consumption, enhanced debug features, and a high level of support block integration. The

ARM Cortex-M33 CPU employs a 3-stage instruction pipe and includes an internal

prefetch unit that supports speculative branching. A hardware floating-point processor is

integrated into the core. On the RT600, the Cortex-M33 is augmented with two hardware

coprocessors providing accelerated support for additional DSP algorithms and

cryptography.

The Cadence Xtensa HiFi 4 Audio DSP engine is a highly optimized audio processor

designed especially for efficient execution of audio and voice codecs and pre- and

post-processing modules. It supports four 32x32-bit MACs, some support for 72-bit

accumulators, limited ability to support eight 32x16-bit MACs, and the ability to issue two

64-bit loads per cycle. There is a floating point unit providing up to four single-precision

IEEE floating point MACs per cycle.

The RT600 provides up to 4.5 MB of on-chip SRAM (plus an additional 128 KB of

tightly-coupled HiFi4 ram) and several high-bandwidth interfaces to access off-chip flash.

The FlexSPI flash interface supports two channels and includes an 32 KB cache and an

on-the-fly decryption engine. The RT600 is designed to allow the Cortex-M33 to operate

at frequencies of up to 300 MHz and the HiFi4 DSP to operate at frequencies of up to 600

MHz.

1.1 Peripherals

The peripheral complement includes an FlexSPI flash interface with two channels, two

SDIO/eMMC interfaces, a high-speed USB device/host with on-chip PHY, a 12-bit, 1

MSamples/sec ADC with temperature sensor, an analog comparator, AES256 and Hash

engines with Physical Unclonable Function (PUF) key generation, a digital microphone

RT600

Dual-core microcontroller with 32-bit Cortex®-M33 and Xtensa

HiFi4 Audio DSP CPUs; Up to 4.5 MB SRAM; FlexSPI with

cache and dynamic decryption; High-speed USB device/host

+ Phy; 12-bit 1 Msamples/s ADC; Analog Comparator; Audio

subsystems supporting up to 8 DMIC channels; SDIO/eMMC;

AES/SHA/Crypto M33 coprocessor; PUF key generation

Rev. 1.7 — 20 January 2021 Product data sheet

Product data sheet Rev. 1.7 — 20 January 2021 2 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

interface supporting up to eight channels and Voice Activation Detect, one I3C interface,

one high-speed SPI interface and seven configurable serial interfaces that can be

configured as a USART, SPI, I2C or I2S bus interface, each including a FIFO. When

configured as USARTs the serial interfaces have the option to operate in deep-sleep

mode using the 32 kHz oscillator or an external clock. There is a dedicated fractional baud

rate generator for each of the serial interfaces.

Timing peripherals include one advanced, 32-bit SCTimer/PWM module, five general

purpose 32-bit timer/counters with PWM capability, a 24-bit, multiple-channel multi-rate

timer, two windowed watchdog timers, a system tick timer with capture capability, and a

Real-time clock module with independent power and a dedicated oscillator. A common OS

Event Timer is provided for synchronized event generation and timestamping between the

two CPUs.

There are two general purpose DMA engines which can service most of the peripherals

described in this section. The two DMA engines may be assigned to different CPUs and/or

one may be used for secure operations, the other for non-secure.

Mailboxes and hardware semaphores are provided to facilitate inter-core communication.

A variety of oscillators and PLLs are available as clock sources throughout the system.

1.2 Shared system SRAM

The entire system SRAM space of up to 4.5 MB is divided into up to 30 separate

partitions, which are accessible to both CPUs, both DMA engines, and all other AHB bus

masters. The HiFi4 CPU accesses the RAM via a dedicated 256-bit interface. Cache (with

single-cycle access) is provided on this interface to improve performance. All other

masters, including the Cortex-M33 processor and the DMA engines, access RAM via the

main 32-bit AHB bus. These accesses are all single-cycle. Hardware interface modules

arbitrate access to each RAM partition between the HiFi4 and the AHB bus.

Under software control, each of the 30 individual SRAM partitions can be used exclusively

as code or as data, dedicated either CPU, or shared among the various masters. Each

partition can be independently placed in a low-power retention mode or powered off

entirely.

In addition to the shared SRAM, a total of 128 KB (64 KB code, 64 KB data) of local,

Tightly-Coupled Memory (TCM) is provided for the exclusive use of the HiFi4 DSP

processor. Access to this memory is single-cycle.

2. Features and benefits

Control processor core

Arm Cortex-M33 processor, running at frequencies of up to 300 MHz.

Arm TrustZone.

Arm Cortex-M33 built-in Memory Protection Unit (MPU) supporting eight regions

Hardware Floating Point Unit (FPU).

Arm Cortex-M33 built-in Nested Vectored Interrupt Controller (NVIC).

Non-maskable Interrupt (NMI) input.

Product data sheet Rev. 1.7 — 20 January 2021 3 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Two coprocessors for the Cortex-M33: a hardware accelerator for fixed and floating

point DSP functions (PowerQuad) and a Crypto/FFT engine (Casper). The DSP

coprocessor uses a bank of four dedicated 2 KB SRAMs. The Crypto/FFT engine

uses a bank of two 2 KB SRAMs that are also AHB accessible by the CPU and the

DMA engine.

Serial Wire Debug with eight break points, four watch points, and a debug

timestamp counter. It includes Serial Wire Output (SWO) trace and ETM trace.

Cortex-M33 System tick timer.

DSP processor core:

Cadence Xtensa HiFi4 Audio DSP processor, running at frequencies of up to

600 MHz.

Hardware Floating Point Unit. Up to four single-precision IEEE floating point MACs

per cycle.

Serial Wire Debug (shared with Cortex-M33 Control Domain CPU).

System tick timer.

Triple I/O power:

Three independent supplies powering different clusters of pins to permit interfacing

directly to off-chip peripherals operating at different supply levels.

On-chip Memory:

Up to 4.5 MB of system SRAM accessible by both CPUs and all (dedicated and

general purpose) DMA engines.

128 KB of local, Tightly-Coupled Memory dedicated to the DSP CPU.

96 KB (or more) of I & D cache for DSP accesses to shared system SRAM.

Additional SRAMs for USB traffic (8 KB), Cortex-M33 coprocessors (4 x 2 KB),

SDIO FIFOs (2 x 512 B dual-port), PUF secure key generation (2 KB), and FlexSPI

cache (32 KB).

16 K bits of OTP fuses for factory and user configuration.

Up to 256 KB ROM memory for factory-programmed drivers and APIs.

System boot from SPI, I2C, UART, Octal/Quad SPI Flash, HS USB or eMMC via

on-chip bootloader software included in ROM.

Digital peripherals:

Two general purpose DMA engines, each with 32 channels and up to 25

programmable request/trigger sources.

- Can be configured such that one DMA is secure and the other non-secure and/or

one can be designated for use by the M33 CPU and the other by the DSP.

USB high-speed host/device controller with on-chip PHY and dedicated DMA

controller.

FlexSPI flash interface with 32 KB cache and dynamic decryption for

execute-in-place and supports DMA. The FlexSPI includes 2 ports: high speed

channel A and lower speed channel B. Both ports support quad or octal operation.

An SD/eMMC memory card interface with dedicated DMA controller. Supports

eMMC 5.0 with HS400/DDR operation (HS-400 is supported only on SD port 0).

Eight configurable universal serial interface modules (Flexcomm Interfaces). Each

module contains an integrated FIFO and DMA support. Flexcomms 0 through 7can

be configured as:

- A USART with dedicated fractional baud rate generation and flow-control

handshaking signals. The USART can optionally be clocked at 32 kHz and

Product data sheet Rev. 1.7 — 20 January 2021 4 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

operated when the chip is in reduced power mode, using either the 32 kHz clock or

an externally supplied clock.The USART also provides partial support for LIN2.2.

- An I2C-bus interface with multiple address recognition, and a monitor mode. It

supports 400 Kb/sec Fast-mode and 1 Mb/sec Fast-mode Plus. It also supports

3.4 Mb/sec high-speed when operating in slave mode.

- An SPI interface.

- An I2S (Inter-IC Sound) interface for digital audio input or output. Each I2S

supports up to four channel-pairs.

One high-speed SPI interface (Flexcomm Interface 14 only) supporting 50 MHz

operation.

One additional I2C interface available on some device configurations (see specific

device data sheet for more information). This interface is intended primarily for

communication with an external power management device (PMIC), but can be

used for other purposes when the application does not use an external PMIC.

One I3C bus interface.

A digital microphone interface supporting up to 8 channels with associated

decimators and Voice Activation Detect. One pair of channels can be streamed

directly to I2S. The DMIC supports DMA.

One 32-bit SCTimer/PWM module (SCT). Multi-purpose timer with extensive

event-generation, match/compare, and complex PWM and output control features.

- Supports DMA and can trigger external DMA events.

- Supports fractional match values for high resolution.

- State machine capability.

- 8 general-purpose inputs.

- 10 general-purpose/PWM outputs

- 16 matches or captures

- 16 events

- 32 states

Five general purpose, 32-bit timer/counter modules with PWM capability.

- Each timer supports four match outputs and four capture inputs.

- Match register auto-reload from shadow registers.

- It supports DMA and can trigger external DMA events.

24-bit multi-rate timer module with four channels, each capable of generating

repetitive interrupts at different programmable frequencies.

Two Windowed Watchdog Timers (WDT) with dedicated watchdog oscillator.

Frequency measurement module to determine the frequency of a selection of

on-chip or off-chip clock sources.

Real-Time Clock (RTC) with independent power supply and dedicated oscillator.

Integrated wake-up timer can be used to wake the device up from low-power

modes. The RTC includes eight 32-bit general purpose registers which can retain

content when power is removed from the rest of the chip.

Ultra-low power micro-tick timer running from the watchdog oscillator with capture

capability for timestamping. Can be used to wake the device up from low-power

modes.

64-bit OS Event Timer common to the Cortex-M33 and DSP processors with

individual match/capture and interrupt generation logic.

CRC engine block can calculate a CRC on supplied data using one of three

standard polynomials. The CRC engine supports DMA.

Product data sheet Rev. 1.7 — 20 January 2021 5 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

AES256 encryption module. The Random Number Generator can be used to

create keys. Key storage is in OTP. The AES supports DMA.

Physical Unclonable Function (PUF) key generation module.

SHA1/SHA2 Secure Hash Algorithm module. Supports secure boot, uses a

dedicated DMA controller.

Cryptography hardware coprocessor attached to Cortex-M33 CPU.

Analog peripherals:

One 12-bit ADC with sampling rates of 1 Msamples/sec and an enhanced ADC

controller. It supports up to 12 single-ended channels or 6 differential channels.

The ADC supports DMA.

Temperature sensor.

Analog comparator.

I/O peripherals:

Up to 147 general purpose I/O (GPIO) pins with configurable pull-up/pull-down

resistors. Ports can be written as words, half-words, bytes, or bits. The number of

GPIOs depends on the device package.

Individual GPIO pins can be used as edge and level sensitive interrupt sources,

each with its own interrupt vector.

All port0 and port1 GPIO pins can contribute to a one of two GPIO interrupts, with

selection of polarity and edge vs level triggering.

A group of up to 8 GPIO pins can be selected for boolean pattern matching, which

can generate interrupts and/or drive a pattern-match output.

Adjustable output drivers.

JTAG boundary scan.

Clock generation unit:

Crystal oscillator with an operating range of 4 MHz to 32 MHz.

Internal 48 or 60 MHz IRC oscillator. Trimmed to  1% accuracy.

Internal 16 MHz IRC oscillator. Trimmed to  3% accuracy.

Internal 1 MHz low-power oscillator with 10% accuracy. Serves as the watchdog

oscillator and clock for the OS Event Timer and the Systick. Also available as the

system clock.

32 kHz real-time clock (RTC) oscillator that can optionally be used as a system

clock.

Selectable on-chip crystal load capacitors for RTC oscillator.

Main System PLL:

- Allows CPU operation up to the maximum rate without the need for a high

frequency crystal. May be run from the 16 MHz IRC, the 48/60 MHz IRC, or the

crystal.

- Second PLL output using an independent fractional divider provides an alternate

high-frequency clock source for the DSP CPU if the required frequency differs from

the main system clock.

- Two additional PLL outputs, each using independent fractional dividers, providing

alternative clock input sources to a number of peripherals.

Audio PLL for the audio subsystem.

480 MHz USB PLL (internal to the USB PHY).

Clock output function with divider that can reflect any of the internal clock sources.

Power control:

Product data sheet Rev. 1.7 — 20 January 2021 6 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Main power supply is 1.8 V +/- 5%.

Analog supply is 1.71 V - 3.6 V.

Triple VDDIO supplies (can be shared or independent): 1.71 V - 3.6 V.

USB Supply: 3.0 V - 3.6 V.

Reduced power modes:

- Sleep mode: Clock shut down for each CPU independently.

- Deep-sleep mode: User selectable configuration via PDSLEEPCFG.

- Deep power-down mode: Power removed from the entire chip except in the

always-on domain.

- Full deep power-down mode: same as deep power-down mode, but external

power can be removed (except for VDD_AO18).

- Each individual SRAM partition can be independently powered-off or put into a

low-power retain mode. Individual SRAMs can also have their clocks stopped when

not actually in use in order to save power.

- Ability to operate the synchronous serial interfaces in sleep or deep-sleep mode

as a slave or USART clocked by the 32 kHz RTC oscillator.

- Wake-up from low-power modes via interrupts from various peripherals including

the RTC and the OS/Event timer.

RBB/FBB to provide additional control over power/performance trade-offs.

Power-On Reset (POR).

Operating temperature range -20 °C to +85 °C

Available in VFBGA176, WLCSP114, and FOWLP249 packages.

Product data sheet Rev. 1.7 — 20 January 2021 7 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

3. Applications

Consumer Audio

Product data sheet Rev. 1.7 — 20 January 2021 8 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

4. Ordering information

Table 1. Ordering information

Type number Package

Name Description Version

MIMXRT685SFFOB FOWLP249 Fan-Out Wafer-Level Packaging; 249 balls; 7 x 7 x 0.76 mm SOT2003-1

MIMXRT685SFVKB VFBGA176 thin fine-pitch ball grid array package; 176 balls; body 9 x 9 x 0.98 mm SOT1850-1

MIMXRT685SFAWBR WLCSP114 wafer level chip-size package; 114; 4.235 x 4.235 x 0.525 mm SOT2019

MIMXRT633SFVKB VFBGA176 thin fine-pitch ball grid array package; 176 balls; body 9 x 9 x 0.98 mm SOT1850-1

MIMXRT633SFAWBR WLCSP114 wafer level chip-size package; 114; 4.235 x 4.235 x 0.525 mm SOT2019

‘23:.

Product data sheet Rev. 1.7 — 20 January 2021 9 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

4.1 Ordering options

[1] On WLCSP114 package, USB ISP mode is not supported. VBUS pin is not available on the WLCSP114 package. To detect VBUS

connection, user can connect a GPIO pin to the USB connector's VBUS. When a rising edge occurs on the GPIO pin, software should

set bit 10 (FORCE_VBUS) and bit 16 (DCON) in the DEVCMDSTAT register.

[2] On WLCSP114 package, the Flexcomm interface 6 can only be used as a UART peripheral, I2C peripheral, or I2S peripheral (using I2S

signal sharing feature).

[3] This interface is intended primarily for communication with an external power management device (PMIC), but can be used for other

purposes when the application does not use an external PMIC.

[4] USB ISP can only boot with an external crystal oscillator of 24 MHz.

Table 2. Ordering options 4

Type number

Package Name

M33

HiFi4 DSP

SRAM/MB

Security Features

FlexSPI A Interface

FlexSPI B Interface

RTC

USB ISP mode[1][4]

Flexcomm Interfaces (0 to 7)

High Speed SPI (Flexcomm 14)

PMIC I2C (Flexcomm 15) [3]

GPIO

SD/MMC

MIMXRT685SFFOB FOWLP249 Yes Yes 4.5 Yes Yes Yes Yes Yes 8 Yes Yes 147 2

MIMXRT685SFVKB VFBGA176 Yes Yes 4.5 Yes Yes Yes Yes Yes 6 Yes Yes 96 1

MIMXRT685SFAWBR WLCSP114 Yes Yes 4.5 Yes Yes No No No 7[2] Yes No 65 -

MIMXRT633SFVKB VFBGA176 Yes No 3 Yes Yes Yes Yes Yes 6 Yes Yes 96 1

MIMXRT633SFAWBR WLCSP114 Yes No 3 Yes Yes No No No 7[2] Yes No 65 -

“”25721

Product data sheet Rev. 1.7 — 20 January 2021 10 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

5. Marking

The MIMXRT6xxSFAWBR WLCSP114 production samples has the following top-side

package marking:

•First line: MRT6xxSF

•Second line: AW[R]R

•Third line: xxxxxx xx

•Fourth line: xxxxyyww

–yyww: Date code with yy = year and ww = week

•Fifth line: xxx-yyy

•Sixth line: NXP

The MIMXRT6xxSFVKB VFBGA176 production samples has the following top-side

package marking:

•First line: MRT6xxSFV

•Second line: K[R] xxxx

•Third line: xyyww

•Fourth line: xxxxx

–yyww: Date code with yy = year and ww = week

The MIMXRT6xxSFFOB FOWLP249 production samples has the following top-side

package marking:

•First line: MRT6xxSFFOB

•Second line: xxxxxx

•Third line: xxxxxx

•Fourth line: xxxxxyyww

–yyww: Date code with yy = year and ww = week

Fig 1. VFBGA 176 package marking Fig 2. WLCSP 114 package marking

Terminal 1 index area

aaa-025721

aaa-015675

Terminal 1

index area

Product data sheet Rev. 1.7 — 20 January 2021 11 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Table 3. Device revision table

Revision identifier Revision description [R]

B Initial device revision

Figure 3 Figure 4 Figure 5 Figure 4

Product data sheet Rev. 1.7 — 20 January 2021 12 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

6. Block diagram

Figure 3, Figure 4, and Figure 5 shows the RT600 block diagram. On Figure 4, shaded

blocks support general purpose DMA or blocks include dedicated DMA control.

Fig 3. Block diagram overview

ARM

Cortex-M33

with FPU&MPU

Debug Interface

Security and

math

coprocessors

200221

clock generation,

power control, reset, and

other system functions

C-AHB S-AHB

AHB Multilayer Matrix

AHB

Peripherals

APB

Peripherals

Boot ROM

On-the-fly

AES

decryption

Octal / Quad

SPI memory

interface

cache

Tensilica

HiFi4 DSP

Instruction

TCM

Data

TCM

Instruction

cache

Data

cache

RAM interface

with arbitration

per port/partition

Shared RAM

(30 partitions,

totaling 4.5 MB)

DSP AHB slave interface

DSP AHB master interface

9 matrix

slave ports

master ports

arbitration

DMAC

Hash-

AES

SDIO/

eMMC

SDIO/

eMMC

and

Product data sheet Rev. 1.7 — 20 January 2021 13 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Fig 4. Block diagram - Cortex-M33 view (Not all features are available in all packages. Flexcomm Interfaces 0 through7 each

include USART, SPI, I2C, and I2S functions. Grey-shaded blocks indicate peripherals that provide DMA requests or are

otherwise able to trigger DMA transfers. Hash-AES and SDIO include a dedicated DMA function.)

Multilayer

AHB Matrix

ARM

Cortex-M33

with FPU&MPU

AHB to

APB bridge

Serial Wire Debug

(shared with DSP)

Debug Interface SDIO/

eMMC

FlexSPI

Flash Intf

On-the-fly AES

decryp (OTFAD)

32 KB

cache

AHB to

APB bridge

PwrQuad

coprocessor

Casper

coprocessor

200221

JTAG boundary scan

HS GPIO

ports 0-4, 7

9 matrix ports connected to 4.5 MB shared RAM

partitions (see related text & figure for details)

RESETCLKOUT

clock generation,

power control,

and other

system functions

Power-On Reset

PLLs

Internal oscillators

Crystal, clock

inputs, etc.

FlexComm

Interfaces 4 to 7 FlexComm Intf

14 (SPI-only)

FlexComm Intf

15 (I2C-only)

DMA0

registers

DMA1

registers

Boot Rom

226 KB

CRC Engine

OS TimerSemaphore

Message

Unit

D-Mic: 8-ch, with

decimator, VAD, etc

16 Kb OTP

array

SDIO0

registers

Random

Number Gen

FlexSPI &

OTFAD regs

ADC: 12-bit,

10 channel

Temp

Sensor

SCTimer/

PWM

Secure

Control regs

USB RAM

(16KB)

HS USB

host regs

HS USB

device regs

Secure

GPIO 0

to DSP inbound PIF

(see related text & figure for details)

PwrQuad

registers

CASPER

RAM

Hash-Crypt

slave i/f

C-AHB S-AHB

APB slave group 0

I/O Configuration

RSTCTLa, CLKCTLa, SYSCTLa

PUF

Windowed Watchdog0

MicroTick Timer

APB slave group 1

RSTCTLb, CLKCTLb, SYSCTLb

GPIO Pin Interrupt Control

5x 32-bit Timers (T0-4)

Periph Input Mux Selects

Multi-Rate Timer

Frequency Measure

I3C

32 kHz osc

& dividers

RTC Alarm Match

RTC Subsec Counter

RTC Alarm Counter

RTC Wake Counter

RTC count

Watchdog

clock

Windowed Watchdog1

Watchdog clock

Always-on

Power Domain

Debug

Mailbox

FlexComm

Interfaces 0 to 3

ACMP

registers

DMAC

HiFi4

DSP

AHB

master

USB PHY

registers

channel A

channel B

DMAC

Hash-

AES

SDIO1

registers

P2 .. P10

P11

P12

P14

P13

P15

P17

P16

arbi-

tration

CASPER

registers

SDIO/

eMMC

HS USB

Bus

USB HS

controller

and PHY

Product data sheet Rev. 1.7 — 20 January 2021 14 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Fig 5. Block diagram - DSP view

180313

Data cache

64 KB, 4-way,

256 bytes/line

Instruction cache

32 KB, 2-way,

256 bytes/line

Data TCM

64 KB, 4 banks

128 bits wide

Instruction TCM

64 KB

128 bits wide

Tensilica

HiFi4 DSP

8x 32 KB

RAM partitions

4x 64 KB

RAM partitions

4x 128 KB

RAM partitions

14x 256 KB

RAM partitions

DSP AHB

slave interface

(from AHB Matrix)

RAM interface

with arbitration

(one per RAM partition)

RAM interface

with arbitration

(one per RAM partition)

RAM interface

with arbitration

(one per RAM partition)

DSP AHB

master interface

AHB memory interface

(9 ports from

system AHB Matrix)

from 3 AHB

matrix ports

from 4 AHB

matrix ports

from 1 AHB

matrix port

from 1 AHB

matrix port

Total of 4.5 MB

Shared RAM

RAM interface

with arbitration

(one per RAM partition)

(to AHB Matrix

master)

Table 4

Product data sheet Rev. 1.7 — 20 January 2021 15 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

7. Pinning information

Tabl e 4 shows the pin functions available on each pin, and for each package. These

functions are selectable using IOCON control registers.

Some functions, such as ADC or comparator inputs, are available only on specific pins

when digital functions are disabled on those pins. By default, the GPIO function is

selected except on pins PIO2_25 and PIO2_26, which are the serial wire debug pins. This

allows debug to operate through reset.

All GPIO pins have all pull-ups and pull-downs turned off at reset. This prevents power

loss through pins prior to software configuration. All GPIO pins are fail safe up to 3.6 V

when VDDIO supply = 0 V except following pins (PIO1_19 to PIO1_31, PIO2_0 to

PIO2_8, PIO0_21, PIO0_22, PIO_23 pins).

The state of pins PIO1_15, PIO1_16, and PIO1_17 at Reset determine the boot source for

the part or if the ISP handler is invoked.

The JTAG functions TRST, TCK, TMS, TDI, and TDO, are selected on pins PIO0_7 to

PIO0_11 by hardware when the part is in boundary scan mode.

Table 4. Pin description

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

PIO0_0 H3 G1 H17 [2] ZI/O 0PIO0_0 — General-purpose digital input/output pin.

I/O 1 FC0_SCK — Flexcomm 0: USART, SPI, or I2S clock.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT0 — 32-bit CTimer0 match output 0.

I5I2S_BRIDGE_CLK_IN — Allows I2S bypass by re-routing

this function to a pin that includes the

I2S_BRIDGE_CLK_OUT function.

O6GPIO_INT_BMAT — Output of the pin interrupt pattern

match engine.

7R — Reserved.

I/O 8 SEC_PIO0_0 — Secure GPIO pin.

Product data sheet Rev. 1.7 — 20 January 2021 16 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_1 H2 G2 H16 [2] ZI/O 0PIO0_1 — General-purpose digital input/output pin.

I/O 1 FC0_TXD_SCL_MISO_WS — Flexcomm 0: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

2R — Reserved.

3R — Reserved

O4CTIMER0_MAT1 — 32-bit CTimer0 match output 1.

I5I2S_BRIDGE_WS_IN — Allows I2S bypass by re-routing this

function to a pin that includes the I2S_BRIDGE_WS_OUT

function.

6R — Reserved.

7R — Reserved

I/O 8 SEC_PIO0_1 — Secure GPIO pin.

PIO0_2 F5 G4 H15 [2] ZI/O 0PIO0_2 — General-purpose digital input/output pin.

I/O 1 FC0_RXD_SDA_MOSI_DATA — Flexcomm 0: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT2 — 32-bit CTimer0 match output 2.

I5I2S_BRIDGE_DATA_IN — Allows I2S bypass by re-routing

this function to a pin that includes the

I2S_BRIDGE_DATA_OUT function.

6R — Reserved.

7R — Reserved

I/O 8 SEC_PIO0_2 — Secure GPIO pin.

PIO0_3 F4 H2 H14 [2] ZI/O 0PIO0_3 — General-purpose digital input/output pin.

I/O 1 FC0_CTS_SDA_SSEL0 — Flexcomm 0: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT3 — 32-bit CTimer0 match output 3.

I/O 5 FC1_SSEL2 — Flexcomm 1: SPI slave select 2.

6R — Reserved.

7R — Reserved

I/O 8 SEC_PIO0_3 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 17 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_4 G1 J1 K17 [2] ZI/O 0PIO0_4 — General-purpose digital input/output pin.

I/O 1 FC0_RTS_SCL_SSEL1 — Flexcomm 0: USART

request-to-send, I2C clock, SPI slave select 1.

2R — Reserved.

3R — Reserved.

I4CTIMER_INP0 — Capture input 0 to CTIMER input muxes.

I/O 5 FC1_SSEL3 — Flexcomm 1: SPI slave select 3.

6R — Reserved.

O7CMP0_OUT — Analog comparator 0 output.

I/O 8 SEC_PIO0_4 — Secure GPIO pin.

PIO0_5/

CH0A

J3 F4 F16 [3] Z I/O;

0PIO0_5/CH0A — General-purpose digital input/output pin.

Analog input 0A. Can optionally be paired with CH0B for

differential input on ADC channel 0.

I/O 1 FC0_SSEL2 — Flexcomm 0: SPI slave select 2.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

O3SCT0_OUT0 — SCTimer/PWM output 0.

I4CTIMER_INP1 — Capture input 1 to CTIMER input muxes.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_5 — Secure GPIO pin.

PIO0_6/

CH0B

J1 E1 F17 [3] Z I/O;

0PIO0_6/CH0B — General-purpose digital input/output pin.

Analog input 0A. Can optionally be paired with CH0B for

differential input on ADC channel 0.

I/O 1 FC0_SSEL3 — Flexcomm 0: SPI slave select 3.

I2SCT0_GPI1 — Pin input 1 to SCTimer/PWM.

O3SCT0_OUT1 — SCTimer/PWM output 1.

O4CTIMER0_MAT0 — 32-bit CTimer0 match output 0.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_6 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 18 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_7/

TRST

F3 J2 J15 [2] ZI/O 0PIO0_7 — General-purpose digital input/output pin. In

boundary scan mode: TRST (Test Reset).

I/O 1 FC1_SCK — Flexcomm 1: USART, SPI, or I2S clock.

I2SCT0_GPI4 — Pin input 4 to SCTimer/PWM.

O3SCT0_OUT4 — SCTimer/PWM output 4.

O4CTIMER1_MAT0 — 32-bit CTimer1 match output 0.

O5I2S_BRIDGE_CLK_OUT — Allows I2S bypass by re-routing

a pin that includes the I2S_BRIDGE_CLK_IN function to this

pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_7 — Secure GPIO pin.

PIO0_8/

TCK

E4 K4 K16 [2] ZI/O 0PIO0_8 — General-purpose digital input/output pin. In

boundary scan mode: TCK (Test Clock In).

I/O 1 FC1_TXD_SCL_MISO_WS — Flexcomm 1: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

I2SCT0_GPI5 — Pin input 5 to SCTimer/PWM.

O3SCT0_OUT5 — SCTimer/PWM output 5.

O4CTIMER1_MAT1 — 32-bit CTimer1 match output 1.

O5I2S_BRIDGE_WS_OUT — Allows I2S bypass by re-routing a

pin that includes the I2S_BRIDGE_WS_IN function to this

pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_8 — Secure GPIO pin.

PIO0_9/

TMS

E3 L3 K15 [2] ZI/O 0PIO0_9 — General-purpose digital input/output pin. In

boundary scan mode: TMS (Test Mode Select).

I/O 1 FC1_RXD_SDA_MOSI_DATA — Flexcomm 1: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

I2SCT0_GPI6 — Pin input 6 to SCTimer/PWM.

O3SCT0_OUT6 — SCTimer/PWM output 6.

O4CTIMER1_MAT2 — 32-bit CTimer1 match output 2.

O5I2S_BRIDGE_DATA_OUT — Allows I2S bypass by

re-routing a pin that includes the I2S_BRIDGE_DATA_IN

function to this pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_9 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 19 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_10/

TDI

E2 J3 L16 [2] ZI/O 0PIO0_10 — General-purpose digital input/output pin. In

boundary scan mode: TDI (Test Data In).

I/O 1 FC1_CTS_SDA_SSEL0 — Flexcomm 1: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

I2SCT0_GPI7 — Pin input 7 to SCTimer/PWM.

O3SCT0_OUT7 — SCTimer/PWM output 7.

O4CTIMER1_MAT3 — 32-bit CTimer1 match output 3.

I/O 5 FC0_SSEL2 — Flexcomm 0: SPI slave select 2.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_10 — Secure GPIO pin.

PIO0_11/

TDO

E1 L1 K13 [2] ZI/O 0PIO0_11 — General-purpose digital input/output pin. In

boundary scan mode: TDO (Test Data Out).

I/O 1 FC1_RTS_SCL_SSEL1 — Flexcomm 1: USART

request-to-send, I2C clock, SPI slave select 1.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

O3SCT0_OUT8 — SCTimer/PWM output 8.

I4CTIMER_INP2 — Capture input 2 to CTIMER input muxes.

I/O 5 FC0_SSEL3 — Flexcomm 0: SPI slave select 3.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_11 — Secure GPIO pin.

PIO0_12/

CH1A

K1 E3 F15 [3] Z I/O;

0PIO0_12/CH1A — General-purpose digital input/output pin.

Analog input 1A. Can optionally be paired with CH1B for

differential input on ADC channel 1.

I/O 1 FC1_SSEL2 — Flexcomm 1: SPI slave select 2.

I2SCT0_GPI2 — Pin input 2 to SCTimer/PWM.

O3SCT0_OUT2 — SCTimer/PWM output 2.

I4CTIMER_INP3 — Capture input 3 to CTIMER input muxes.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_12 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 20 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_13/

CH1B

G4 G3 G16 [3] Z I/O;

0PIO0_13/CH1B — General-purpose digital input/output pin.

Analog input 1B. Can optionally be paired with CH1A for

differential input on ADC channel 1.

I/O 1 FC1_SSEL3 — Flexcomm 1: SPI slave select 3.

I2SCT0_GPI3 — Pin input 3 to SCTimer/PWM.

O3SCT0_OUT3 — SCTimer/PWM output 3.

O4CTIMER0_MAT1 — 32-bit CTimer0 match output 1.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_13 — Secure GPIO pin.

PIO0_14 K4 A3 B17 [2] ZI/O 0PIO0_14 — General-purpose digital input/output pin.

I/O 1 FC2_SCK — Flexcomm 1: USART, SPI, or I2S clock.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

O3SCT0_OUT0 — SCTimer/PWM output 0.

O4CTIMER2_MAT0 — 32-bit CTimer2 match output 0.

I5I2S_BRIDGE_CLK_IN — Allows I2S bypass by re-routing

this function to a pin that includes the

I2S_BRIDGE_CLK_OUT function.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_14 — Secure GPIO pin.

PIO0_15 J6 A5 A16 [2] ZI/O 0PIO0_15 — General-purpose digital input/output pin.

I/O 1 FC2_TXD_SCL_MISO_WS — Flexcomm 2: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

I2SCT0_GPI1 — Pin input 1 to SCTimer/PWM.

O3SCT0_OUT1 — SCTimer/PWM output 1.

O4CTIMER2_MAT1 — 32-bit CTimer2 match output 1.

I5I2S_BRIDGE_WS_IN — Allows I2S bypass by re-routing this

function to a pin that includes the I2S_BRIDGE_WS_OUT

function.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_15 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 21 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_16 K5 D6 B12 [2] ZI/O 0PIO0_16 — General-purpose digital input/output pin.

I/O 1 FC2_RXD_SDA_MOSI_DATA — Flexcomm 2: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

I2SCT0_GPI2 — Pin input 2 to SCTimer/PWM.

O3SCT0_OUT2 — SCTimer/PWM output 2.

O4CTIMER2_MAT2 — 32-bit CTimer2 match output 2.

I5I2S_BRIDGE_DATA_IN — Allows I2S bypass by re-routing

this function to a pin that includes the

I2S_BRIDGE_DATA_OUT function.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_16 — Secure GPIO pin.

PIO0_17 - D7 B14 [2] ZI/O 0PIO0_17 — General-purpose digital input/output pin.

I/O 1 FC2_CTS_SDA_SSEL0 — Flexcomm 2: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

I2SCT0_GPI3 — Pin input 3 to SCTimer/PWM.

O3SCT0_OUT3 — SCTimer/PWM output 3.

O4CTIMER2_MAT3 — 32-bit CTimer2 match output 3.

I/O 5 FC5_SSEL2 — Flexcomm 5: SPI slave select 2.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_17 — Secure GPIO pin.

PIO0_18 - B7 A14 [2] ZI/O 0PIO0_18 — General-purpose digital input/output pin.

I/O 1 FC2_RTS_SCL_SSEL1 — Flexcomm 2: USART

request-to-send, I2C clock, SPI slave select 1.

I2SCT0_GPI6 — Pin input 6 to SCTimer/PWM.

O3SCT0_OUT6 — SCTimer/PWM output 6.

I4CTIMER_INP4 — Capture input 4 to CTIMER input muxes.

I/O 5 FC5_SSEL3 — Flexcomm 5: SPI slave select 3.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_18 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 22 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_19/

CH2A

H6 A1 D12 [3] Z I/O;

0PIO0_19/CH2A — General-purpose digital input/output pin.

Analog input 2A. Can optionally be paired with CH2B for

differential input on ADC channel 2.

I/O 1 FC2_SSEL2 — Flexcomm 2: SPI slave select 2.

I2SCT0_GPI4 — Pin input 4 to SCTimer/PWM.

O3SCT0_OUT4 — SCTimer/PWM output 4.

I4CTIMER_INP5 — Capture input 5 to CTIMER input muxes.

I5UTICK_CAP0 — Micro-tick timer capture input 0.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_19 — Secure GPIO pin.

PIO0_20/

CH2B

H5 B2 E13 [3] Z I/O;

0PIO0_20/CH2B — General-purpose digital input/output pin.

Analog input 2B. Can optionally be paired with CH2A for

differential input on ADC channel 2.

I/O 1 FC2_SSEL3 — Flexcomm 2: SPI slave select 3.

I2SCT0_GPI5 — Pin input 5 to SCTimer/PWM.

O3SCT0_OUT5 — SCTimer/PWM output 5.

O4CTIMER0_MAT2 — 32-bit CTimer0 match output 2.

I5CTIMER_INP11 — Capture input 11 to CTIMER input muxes.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_20 — Secure GPIO pin.

PIO0_21 L5 C7 A12 [2] ZI/O 0PIO0_21 — General-purpose digital input/output pin.

I/O 1 FC3_SCK — Flexcomm 3: USART, SPI, or I2S clock.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT0 — 32-bit CTimer3 match output 0.

5R — Reserved.

O6TRACECLK — Trace clock.

7R — Reserved.

I/O 8 SEC_PIO0_21 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 23 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_22 H7 D8 A10 [2] ZI/O 0PIO0_22 — General-purpose digital input/output pin.

I/O 1 FC3_TXD_SCL_MISO_WS — Flexcomm 3: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT1 — 32-bit CTimer3 match output 1.

5R — Reserved.

O6TRACEDATA[0] — Trace data bit 0.

7R — Reserved.

I/O 8 SEC_PIO0_22 — Secure GPIO pin.

PIO0_23 K7 C9 A8 [2] ZI/O 0PIO0_23/ — General-purpose digital input/output pin.

I/O 1 FC3_RXD_SDA_MOSI_DATA — Flexcomm 3: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT2 — 32-bit CTimer3 match output 2.

5R — Reserved.

O6TRACEDATA[1] — Trace data bit 1.

7R — Reserved.

I/O 8 SEC_PIO0_23 — Secure GPIO pin.

PIO0_24 H8 B9 B8 [2] ZI/O 0PIO0_24 — General-purpose digital input/output pin.

I/O 1 FC3_CTS_SDA_SSEL0 — Flexcomm 3: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT3 — 32-bit CTimer3 match output 3.

I/O 5 FC2_SSEL2 — Flexcomm 2: SPI slave select 2.

O6TRACEDATA[2] — Trace data bit 2.

O7CLKOUT — Output of the CLKOUT function.

I/O 8 SEC_PIO0_24 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 24 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_25 L6 A9 B7 [2] ZI/O 0PIO0_25 — General-purpose digital input/output pin.

I/O 1 FC3_RTS_SCL_SSEL1 — Flexcomm 3: USART

request-to-send, I2C clock, SPI slave select 1.

2R — Reserved.

I3FREQME_GPIO_CLK — Frequency Measure pin clock

input.

I4CTIMER_INP6 — Capture input 6 to CTIMER input muxes.

I/O 5 FC2_SSEL3 — Flexcomm 2: SPI slave select 3.

O6TRACEDATA[3] — Trace data bit 3.

I7CLKIN — Clock input.

I/O 8 SEC_PIO0_25 — Secure GPIO pin.

PIO0_26/

CH3A

L3 A2 B16 [3] ZI/O;

0PIO0_26/CH3A — General-purpose digital input/output pin.

Analog input 3A. Can optionally be paired with CH3B for

differential input on ADC channel 3.

I/O 1 FC3_SSEL2 — Flexcomm 3: SPI slave select 2.

I2SCT0_GPI6 — Pin input 6 to SCTimer/PWM.

O3SCT0_OUT6 — SCTimer/PWM output 6.

I4CTIMER_INP7 — Capture input 7 to CTIMER input muxes.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_26 — Secure GPIO pin.

PIO0_27/

CH3B

J4 B3 D13 [3] Z I/O;

0PIO0_27/CH3B — General-purpose digital input/output pin.

Analog input 3B. Can optionally be paired with CH3A for

differential input on ADC channel 3.

I/O 1 FC3_SSEL3 — Flexcomm 3: SPI slave select 3.

I2SCT0_GPI7 — Pin input 7 to SCTimer/PWM.

O3SCT0_OUT7 — SCTimer/PWM output 7.

O4CTIMER0_MAT3 — 32-bit CTimer0 match output 3.

5R — Reserved.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_27 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 25 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_28 - D11 A6 [2] ZI/O 0PIO0_28 — General-purpose digital input/output pin.

I/O 1 FC4_SCK — Flexcomm 4: USART, SPI, or I2S clock.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT0 — 32-bit CTimer4 match output 0.

O5I2S_BRIDGE_CLK_OUT — Allows I2S bypass by re-routing

a pin that includes the I2S_BRIDGE_CLK_IN function to this

pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_28 — Secure GPIO pin.

PIO0_29 K8 B10 B6 [2] ZI/O 0PIO0_29 — General-purpose digital input/output pin.

I/O 1 FC4_TXD_SCL_MISO_WS — Flexcomm 0: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT1 — 32-bit CTimer4 match output 1.

O5I2S_BRIDGE_WS_OUT — Allows I2S bypass by re-routing a

pin that includes the I2S_BRIDGE_WS_IN function to this

pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_29 — Secure GPIO pin.

PIO0_30 L8 C11 C6 [2] ZI/O 0PIO0_30 — General-purpose digital input/output pin.

I/O 1 FC4_RXD_SDA_MOSI_DATA — Flexcomm 4: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT2 — 32-bit CTimer4 match output 2.

O5I2S_BRIDGE_DATA_OUT — Allows I2S bypass by

re-routing a pin that includes the I2S_BRIDGE_DATA_IN

function to this pin.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_30 — Secure GPIO pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 26 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO0_31 - A11 B1 [2] ZI/O 0PIO0_31 — General-purpose digital input/output pin.

I/O 1 FC4_CTS_SDA_SSEL0 — Flexcomm 4: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

O3SCT0_OUT6 — SCTimer/PWM output 6.

O4CTIMER4_MAT3 — 32-bit CTimer4 match output 3.

I/O 5 FC3_SSEL2 — Flexcomm 3: SPI slave select 2.

6R — Reserved.

7R — Reserved.

I/O 8 SEC_PIO0_31 — Secure GPIO pin.

PIO1_0 - E17 H4 [3] ZI/O 0PIO1_0 — General-purpose digital input/output pin.

I/O 1 FC4_RTS_SCL_SSEL1 — Flexcomm 4: USART

request-to-send, I2C clock, SPI slave select 1.

I2SCT0_GPI1 — Pin input 1 to SCTimer/PWM.

O3SCT0_OUT7 — SCTimer/PWM output 7.

I4CTIMER_INP8 — Capture input 8 to CTIMER input muxes.

I/O 5 FC3_SSEL3 — Flexcomm 3: SPI slave select 3.

PIO1_1 - G15 H5 [2] ZI/O 0PIO1_1 — General-purpose digital input/output pin.

I/O 1 FC4_SSEL2 — Flexcomm 4: SPI slave select 2.

I2SCT0_GPI2 — Pin input 2 to SCTimer/PWM.

O3SCT0_OUT8 — SCTimer/PWM output 8.

O4CTIMER1_MAT0 — 32-bit CTimer1 match output 0.

PIO1_2/

CMP0_C

K6 A7 B11 [3] Z I/O;

0PIO1_2/CMP0_C — General-purpose digital input/output pin.

Analog comparator input C if the DIGIMODE bit is set to 0

and ANAMODE is set to 1 in the IOCON register for this pin.

I/O 1 FC4_SSEL3 — Flexcomm 4: SPI slave select 3.

I2SCT0_GPI3 — Pin input 3 to SCTimer/PWM.

O3SCT0_OUT9 — SCTimer/PWM output 9.

O4CTIMER1_MAT1 — 32-bit CTimer1 match output 1.

PIO1_3 F10 G16 J4 [2] ZI/O 0PIO1_3 — General-purpose digital input/output pin.

I/O 1 FC5_SCK — Flexcomm 5: USART, SPI, or I2S clock.

PIO1_4 F9 G17 H3 [2] ZI/O 0PIO1_4 — General-purpose digital input/output pin.

I/O 1 FC5_TXD_SCL_MISO_WS — Flexcomm 5: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

PIO1_5 E11 J16 J3 [2] ZI/O 0PIO1_5 — General-purpose digital input/output pin.

I/O 1 FC5_RXD_SDA_MOSI_DATA — Flexcomm 5: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 27 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO1_6 - J17 K3 [2] ZI/O 0PIO1_6 — General-purpose digital input/output pin.

I/O 1 FC5_CTS_SDA_SSEL0 — Flexcomm 5: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

I2SCT0_GPI4 — Pin input 4 to SCTimer/PWM.

O3SCT0_OUT4 — SCTimer/PWM output 4.

4R — Reserved.

I/O 5 FC4_SSEL2 — Flexcomm 4: SPI slave select 2.

PIO1_7 - J15 E3 [2] ZI/O 0PIO1_7 — General-purpose digital input/output pin.

I/O 1 FC5_RTS_SCL_SSEL1 — Flexcomm 5: USART

request-to-send, I2C clock, SPI slave select 1.

I2SCT0_GPI5 — Pin input 5 to SCTimer/PWM.

O3SCT0_OUT5 — SCTimer/PWM output 5.

I4CTIMER_INP9 — Capture input 9 to CTIMER input muxes.

I/O 5 FC4_SSEL3 — Flexcomm 4: SPI slave select 3.

PIO1_8/

CH4A

J5 B5 B15 [3] Z I/O;

0PIO1_8/CH4A — General-purpose digital input/output pin.

Analog input 4A. Can optionally be paired with CH4B for

differential input on ADC channel 4.

I/O 1 FC5_SSEL2 — Flexcomm 5: SPI slave select 2.

I2SCT0_GPI6 — Pin input 6 to SCTimer/PWM.

I3CTIMER_INP12 — Capture input 12 to CTIMER input muxes.

O4CTIMER1_MAT2 — 32-bit CTimer1 match output 2.

PIO1_9/

CH4B

K3 B1 E14 [3] Z I/O;

0PIO1_9/CH4B — General-purpose digital input/output pin.

Analog input 4B. Can optionally be paired with CH4A for

differential input on ADC channel 4.

I/O 1 FC5_SSEL3 — Flexcomm 5: SPI slave select 3.

I2SCT0_GPI7 — Pin input 7 to SCTimer/PWM.

I3UTICK_CAP1 — Micro-tick timer capture input 1.

O4CTIMER1_MAT3 — 32-bit CTimer1 match output 3.

PIO1_10 E10 K16 F2 [2] ZI/O 0PIO1_10 — General-purpose digital input/output pin.

I/O 1 MCLK — MCLK input or output for I2S and/or digital

microphone.

2R — Reserved.

I3FREQME_GPIO_CLK — Frequency Measure pin clock

input.

I4CTIMER_INP10 — Capture input 10 to CTIMER input muxes.

5R — Reserved.

6R — Reserved.

O7CLKOUT — Output of the CLKOUT function.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 28 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO1_11 E5 L2 K14 [2] ZI/O 0PIO1_11 — General-purpose digital input/output pin.

I/O 1 HS_SPI_SCK — Clock for high speed SPI.

2R — Reserved.

3R — Reserved.

O4CTIMER2_MAT0 — 32-bit CTimer2 match output 0.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA0 — Data bit 0 for the FlexSPI B interface.

PIO1_12 D2 M2 M17 [2] ZI/O 0PIO1_12 — General-purpose digital input/output pin.

I/O 1 HS_SPI_MISO — Master-in/slave-out data for high speed

SPI.

2R — Reserved.

3R — Reserved.

O4CTIMER2_MAT1 — 32-bit CTimer2 match output 1.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA1 — Data bit 1 for the FlexSPI B interface.

PIO1_13 D3 N1 M16 [2] ZI/O 0PIO1_13 — General-purpose digital input/output pin.

I/O 1 HS_SPI_MOSI — Master-out/slave-in data for high speed

SPI.

2R — Reserved

3R — Reserved.

O4CTIMER2_MAT2 — 32-bit CTimer2 match output 2.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA2 — Data bit 2 for the FlexSPI B interface.

PIO1_14 D4 N2 M14 [2] ZI/O 0PIO1_14 — General-purpose digital input/output pin.

I/O 1 HS_SPI_SSEL0 — Slave Select 0 for high speed SPI.

2R — Reserved.

3R — Reserved.

O4CTIMER2_MAT3 — 32-bit CTimer2 match output 3.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA3 — Data bit 3 for the FlexSPI B interface.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 29 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO1_15 C2 N3 M15 [2] ZI/O 0PIO1_15 — General-purpose digital input/output pin.

Remark: The state of this pin at Reset in conjunction with

PIO1_16 and PIO1_17 will determine the boot source for the

part or if ISP handler is invoked. See the Boot Process

chapter in the relevant User Manual for more details.

I/O 1 HS_SPI_SSEL1 — Slave Select 1 for high speed SPI.

2R — Reserved

3R — Reserved

O4CTIMER3_MAT0 — 32-bit CTimer3 match output 0.

PIO1_16 C3 M4 P17 [2] ZI/O 0PIO1_16 — General-purpose digital input/output pin.

Remark: The state of this pin at Reset in conjunction with

PIO1_15 and PIO1_17 will determine the boot source for the

part or if ISP handler is invoked. See the Boot Process

chapter in the relevant User Manual for more details.

I/O 1 HS_SPI_SSEL2 — Slave Select 2 for high speed SPI.

O2SCT0_OUT8 — SCTimer/PWM output 8.

3R — Reserved.

O4CTIMER3_MAT1 — 32-bit CTimer3 match output 1.

PIO1_17 B2 N4 M13 [2] ZI/O 0PIO1_17 — General-purpose digital input/output pin.

Remark: The state of this pin at Reset in conjunction with

PIO1_15 and PIO1_16 will determine the boot source for the

part or if ISP handler is invoked. See the Boot Process

chapter in the relevant User Manual for more details.

I/O 1 HS_SPI_SSEL3 — Slave Select 3 for high speed SPI.

O2SCT0_OUT9 — SCTimer/PWM output 9.

3R — Reserved.

O4CTIMER3_MAT2 — 32-bit CTimer3 match output 2.

PIO1_18 B7 T9 U4 [2] ZI/O 0PIO1_18 — General-purpose digital input/output pin.

O1FLEXSPI0A_SCLK — Clock output for the FlexSPI A

interface.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

3R — Reserved.

O4CTIMER3_MAT3 — 32-bit CTimer3 match output 3.

PIO1_19 B4 T4 U16 [2] ZI/O 0PIO1_19 — General-purpose digital input/output pin.

O1FLEXSPI0A_SS0_N — Active low slave select 0 for the

FlexSPI A interface.

O2SCT0_OUT0 — SCTimer/PWM output 0.

3R — Reserved.

O4CTIMER4_MAT0 — 32-bit CTimer4 match output 0.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 30 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO1_20 C6 T5 T12 [2] ZI/O 0PIO1_20 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA0 — Data bit 0 for the FlexSPI A interface.

I2SCT0_GPI1 — Pin input 1 to SCTimer/PWM.

3R — Reserved.

O4CTIMER4_MAT1 — 32-bit CTimer4 match output 1.

PIO1_21 C7 U5 U12 [2] ZI/O 0PIO1_21 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA1 — Data bit 1 for the FlexSPI A interface.

O2SCT0_OUT1 — SCTimer/PWM output 1.

3R — Reserved.

O4CTIMER4_MAT2 — 32-bit CTimer4 match output 2.

PIO1_22 B5 P6 T11 [2] ZI/O 0PIO1_22 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA2 — Data bit 2 for the FlexSPI A interface.

I2SCT0_GPI2 — Pin input 2 to SCTimer/PWM.

3R — Reserved.

O4CTIMER4_MAT3 — 32-bit CTimer4 match output 3.

PIO1_23 A5 P7 T10 [2] ZI/O 0PIO1_23 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA3 — Data bit 3 for the FlexSPI A interface.

O2SCT0_OUT2 — SCTimer/PWM output 2.

3R — Reserved.

I4CTIMER_INP8 — Capture input 8 to CTIMER input muxes.

PIO1_24 - T7 U10 [2] ZI/O 0PIO1_24 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA4 — Data bit 4 for the FlexSPI A interface.

I2SCT0_GPI3 — Pin input 3 to SCTimer/PWM.

3R — Reserved.

PIO1_25 - U7 U8 [2] ZI/O 0PIO1_25 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA5 — Data bit 5 for the FlexSPI A interface.

O2SCT0_OUT3 — SCTimer/PWM output 3.

3R — Reserved.

PIO1_26 - R7 U6 [2] ZI/O 0PIO1_26 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA6 — Data bit 6 for the FlexSPI A interface.

I2SCT0_GPI4 — Pin input 4 to SCTimer/PWM.

3R — Reserved.

PIO1_27 - T8 T7 [2] ZI/O 0PIO1_27 — General-purpose digital input/output pin.

I/O 1 FLEXSPI0A_DATA7 — Data bit 7 for the FlexSPI A interface.

O2SCT0_OUT4 — SCTimer/PWM output 4.

3R — Reserved.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 31 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO1_28 - U9 T6 [2] ZI/O 0PIO1_28 — General-purpose digital input/output pin.

O1FLEXSPI0A_DQS — Data strobe output for the FlexSPI A

interface.

I2SCT0_GPI5 — Pin input 5 to SCTimer/PWM.

3R — Reserved.

4R — Reserved.

PIO1_29 - U3 U14 [2] ZI/O 0PIO1_29 — General-purpose digital input/output pin.

O1FLEXSPI0A_SS1_N — Active low slave select 1 for the

FlexSPI A interface.

I/O 2 SCT0_OUT5 — SCTimer/PWM output 5.

I3UTICK_CAP2 — Micro-tick timer capture input 2.

I4CTIMER_INP13 — Capture input 13 to CTIMER input muxes.

O5FLEXSPI0A_SCLK_N or FLEXSPI0B_SCLK — Inverted

clock output for the FlexSPI A interface or

Clock output for the FlexSPI B interface.

PIO1_30 - P10 P5 [2] ZI/O 0PIO1_30 — General-purpose digital input/output pin.

O1SD0_CLK — SD/MMC0 clock.

I2SCT0_GPI0 — Pin input 0 to SCTimer/PWM.

PIO1_31 - R9 N8 [2] ZI/O 0PIO1_31 — General-purpose digital input/output pin.

I/O 1 SD0_CMD — SD/MMC0 card command I/O.

I2SCT0_GPI1 — Pin input 1 to SCTimer/PWM.

PIO2_0 - R11 N6 [3] ZI/O 0PIO2_0 — General-purpose digital input/output pin.

I/O 1 SD0_D[0] — SD/MMC0 interface data 0.

I2SCT0_GPI2 — Pin input 2 to SCTimer/PWM.

PIO2_1 - T11 K6 [3] ZI/O 0PIO2_1 — General-purpose digital input/output pin.

I/O 1 SD0_D[1] — SD/MMC0 interface data 1.

I2SCT0_GPI3 — Pin input 3 to SCTimer/PWM.

PIO2_2 - U11 P6 [3] ZI/O 0PIO2_2 — General-purpose digital input/output pin.

I/O 1 SD0_D[2] — SD/MMC0 interface data 2.

O2SCT0_OUT0 — SCTimer/PWM output 0.

PIO2_3 - T12 M5 [2] ZI/O 0PIO2_3 — General-purpose digital input/output pin.

I/O 1 SD0_D[3] — SD/MMC0 interface data 3.

O2SCT0_OUT1 — SCTimer/PWM output 1.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 32 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_4 - T13 N5 [2] ZI/O 0PIO2_4 — General-purpose digital input/output pin.

I1SD0_WR_PRT — SD/MMC 0 write protect.

O2SCT0_OUT2 — SCTimer/PWM output 2.

3R — Reserved.

4R — Reserved.

I5SD0_DS — Read data strobe from SD/MMC0 device.

PIO2_5 - U13 M4 [2] ZI/O 0PIO2_5 — General-purpose digital input/output pin.

I/O 1 SD0_D[4] — SD/MMC0 interface data 4.

O2SCT0_OUT3 — SCTimer/PWM output 3.

3R — Reserved.

PIO2_6 - U15 P4 [2] ZI/O 0PIO2_6 — General-purpose digital input/output pin.

I/O 1 SD0_D[5] — SD/MMC0 interface data 5.

I2SCT0_GPI4 — Pin input 4 to SCTimer/PWM.

3R — Reserved.

O4CTIMER1_MAT0 — 32-bit CTimer1 match output 0.

PIO2_7 - U16 N4 [2] ZI/O 0PIO2_7 — General-purpose digital input/output pin.

I/O 1 SD0_D[6] — SD/MMC0 interface data 6.

I2SCT0_GPI5 — Pin input 5 to SCTimer/PWM.

3R — Reserved.

O4CTIMER1_MAT1 — 32-bit CTimer1 match output 1.

PIO2_8 - U17 M1 [2] ZI/O 0PIO2_8 — General-purpose digital input/output pin.

I/O 1 SD0_D[7] — SD/MMC0 interface data 7.

O2SCT0_OUT4 — SCTimer/PWM output 4.

3R — Reserved.

O4CTIMER1_MAT2 — 32-bit CTimer1 match output 2.

PIO2_9 - R13 M2 [2] ZI/O 0PIO2_9 — General-purpose digital input/output pin.

I1SD0_CARD_DET_N — SD/MMC 0 card detect (active low).

O2SCT0_OUT5 — SCTimer/PWM output 5.

3R — Reserved.

O4CTIMER1_MAT3 — 32-bit CTimer1 match output 3.

PIO2_10 - T15 M3 [2] ZI/O 0PIO2_10 — General-purpose digital input/output pin.

O1SD0_RESET_N — SD/MMC0 card hardware reset, active

low.

I2SCT0_GPI6 — Pin input 6 to SCTimer/PWM.

3R — Reserved.

O4CTIMER2_MAT0 — 32-bit CTimer2 match output 0.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 33 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_11 - T16 N3 [2] ZI/O 0PIO2_11 — General-purpose digital input/output pin.

O1SD0_VOLT — SD/MMC0 card regulator voltage control.

I2SCT0_GPI7 — Pin input 7 to SCTimer/PWM.

3R — Reserved.

O4CTIMER2_MAT1 — 32-bit CTimer2 match output 1.

PIO2_12 - T3 T14 [2] ZI/O 0PIO2_12 — General-purpose digital input/output pin.

1R — Reserved.

O2SCT0_OUT6 — SCTimer/PWM output 6.

3R — Reserved.

O4CTIMER2_MAT2 — 32-bit CTimer2 match output 2.

PIO2_13 - T1 N15 [2] ZI/O 0PIO2_13 — General-purpose digital input/output pin.

1R — Reserved.

O2SCT0_OUT7 — SCTimer/PWM output 7.

3R — Reserved.

O4CTIMER2_MAT3 — 32-bit CTimer2 match output 3.

5R — Reserved.

6R — Reserved.

O7CMP0_OUT — Analog comparator 0 output.

PIO2_14/

CMP0_A

G5 C1 F14 [3] Z I/O;

0PIO2_14/CMP0_A — General-purpose digital input/output

pin. Analog comparator input A if the DIGIMODE bit is set to 0

and ANAMODE is set to 1 in the IOCON register for this pin.

1R — Reserved.

O2SCT0_OUT8 — SCTimer/PWM output 8.

3R — Reserved.

I4CTIMER_INP1 — Capture input 1 to CTIMER input muxes.

PIO2_15/

CMP0_D

H4 E2 F13 [3] Z I/O;

0PIO2_15/CMP0_D — General-purpose digital input/output

pin. Analog comparator input D if the DIGIMODE bit is set to 0

and ANAMODE is set to 1 in the IOCON register for this pin.

1R — Reserved.

O2SCT0_OUT9 — SCTimer/PWM output 9.

3R — Reserved.

4R — Reserved.

5R — Reserved.

6R — Reserved.

I7CLKIN — Clock input.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 34 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_16 B3 R1 P16 [2] ZI/O 0PIO2_16 — General-purpose digital input/output pin.

O1PDM_CLK01 — PDM clock output for DMIC channels 0 and

2R — Reserved.

3R — Reserved.

PIO2_17 C4 U1 R16 [2] ZI/O 0PIO2_17 — General-purpose digital input/output pin.

O1PDM_CLK23 — PDM clock output for DMIC channels 2 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA4 — Data bit 4 for the FlexSPI B interface.

PIO2_18 B1 R2 P15 [2] ZI/O 0PIO2_18 — General-purpose digital input/output pin.

O1PDM_CLK45 — PDM clock output for DMIC channels 4 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA5 — Data bit 5 for the FlexSPI B interface.

PIO2_19 A2 T2 N14 [2] ZI/O 0PIO2_19 — General-purpose digital input/output pin.

O1PDM_CLK67 — PDM clock output for DMIC channels 6 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

O6FLEXSPI0B_SS0_N — Active low slave select 0 for the

FlexSPI B interface.

PIO2_20 C5 U2 N13 [2] ZI/O 0PIO2_20 — General-purpose digital input/output pin.

I1PDM_DATA01 — PDM data input for DMIC channels 0 and

2R — Reserved.

3R — Reserved.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 35 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_21 A3 R3 P13 [2] ZI/O 0PIO2_21 — General-purpose digital input/output pin.

I1PDM_DATA23 — PDM data input for DMIC channels 2 and

2R — Reserved.

3R — Reserved.

I4CTIMER_INP14 — Capture input 14 to CTIMER input muxes.

5R — Reserved.

O6FLEXSPI0B_SS1_N — Active low slave select 1 for the

FlexSPI B interface.

PIO2_22 - P3 P14 [2] ZI/O 0PIO2_22 — General-purpose digital input/output pin.

I1PDM_DATA45 — PDM data input for DMIC channels 4 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA6 — Data bit 6 for the FlexSPI B interface.

PIO2_23 - P5 R14 [2] ZI/O 0PIO2_23 — General-purpose digital input/output pin.

I1PDM_DATA67 — PDM data input for DMIC channels 6 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

I/O 6 FLEXSPI0B_DATA7 — Data bit 7 for the FlexSPI B interface.

PIO2_24 - L16 G2 [2] ZI/O 0PIO2_24 — General-purpose digital input/output pin.

O1SWO — Serial Wire Debug trace output.

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

O6GPIO_INT_BMAT — Output of the pin interrupt pattern

match engine.

PIO2_25 D8 L17 F1 [2] ZI/O 0PIO2_25 — General-purpose digital input/output pin.

O1SWCLK — Serial Wire Debug clock. This is the default

function after booting. Since the internal pull-ups are disabled

by default, connect external pull-up resistor (~10 Kohm) on

SWCLK pin to comply with the ARM SWD interface spec.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 36 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_26 D10 L15 H2 [2] ZI/O 0PIO2_26 — General-purpose digital input/output pin.

I/O 1 SWDIO — Serial Wire Debug I/O. This is the default function

after booting. Since the internal pull-ups are disabled by

default, connect external pull-up resistor (~10 Kohm) on

SWDIO pin to comply with the ARM SWD interface spec.

PIO2_27 D9 M14 H1 [2] ZI/O 0PIO2_27 — General-purpose digital input/output pin.

I1USB1_OVERCURRENTN — USB1 bus overcurrent indicator

(active low). USB host only function. Port power fault signal

indicating over-current condition. This signal monitors

over-current on the USB bus (external circuitry required to

detect over-current condition, active LOW)

PIO2_28 C8 N15 K2 [2] ZI/O 0PIO2_28 — General-purpose digital input/output pin.

O1USB1_PORTPWRN — USB1 VBUS drive enable (Indicates

VBUS must supplied in host mode).

PIO2_29 C11 N17 L2 [2] ZI/O 0PIO2_29 — General-purpose digital input/output pin.

I/O 1 I3C0_SCL — Clock for I3C master or slave.

O2SCT0_OUT0 — SCTimer/PWM output 0.

3R — Reserved.

4R — Reserved.

O5CLKOUT — Output of the CLKOUT function.

PIO2_30 C9 P16 K1 [2] ZI/O 0PIO2_30 — General-purpose digital input/output pin.

I/O 1 I3C0_SDA — Data for I3C master or slave.

O2SCT0_OUT3 — SCTimer/PWM output 3.

3R — Reserved.

4R — Reserved.

I5CLKIN — Clock input.

6R — Reserved.

O7CMP0_OUT — Analog comparator 0 output.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 37 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO2_31/

CMP0_B

J7 B6 C12 [3] Z I/O;

0PIO2_31/CMP0_B — General-purpose digital input/output

pin. Analog comparator input B if the DIGIMODE bit is set to 0

and ANAMODE is set to 1 in the IOCON register for this pin.

O1I3C0_PUR — Pullup resistor control for I3C master. The

I3C0_PUR function controls the SDA pull-up. It is intended to

be connected to one end of an external low-value pull-up

resistor (e.g. 1KOhm), with the other end connected to the

SDA line. If there is no external high weak bus keeper on

SDA, then add an additional external weak (e.g. 100KR or

even 500KR) always-on pull-up on this line.

O2SCT0_OUT7 — SCTimer/PWM output 7.

I3UTICK_CAP3 — Micro-tick timer capture input 3.

I4CTIMER_INP15 — Capture input 15 to CTIMER input muxes.

O5SWO — Serial Wire Debug trace output.

PIO3_0 - - D14 [2] ZI/O 0PIO3_0 — General-purpose digital input/output pin.

O1PDM_CLK01 — PDM clock output for DMIC channels 0 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

5FC0_SCK — Flexcomm 0: USART, SPI, or I2S clock.

PIO3_1 - - D15 [2] ZI/O 0PIO3_1 — General-purpose digital input/output pin.

O1PDM_CLK23 — PDM clock output for DMIC channels 2 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_TXD_SCL_MISO_WS — Flexcomm 0: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

PIO3_2 - - D16 [2] ZI/O 0PIO3_2 — General-purpose digital input/output pin.

O1PDM_CLK45 — PDM clock output for DMIC channels 4 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_RXD_SDA_MOSI_DATA — Flexcomm 0: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 38 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO3_3 - - D17 [2] ZI/O 0PIO3_3 — General-purpose digital input/output pin.

O1PDM_CLK67 — PDM clock output for DMIC channels 6 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_CTS_SDA_SSEL0 — Flexcomm 0: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

6R — Reserved.

O7CMP0_OUT — Analog comparator 0 output.

PIO3_4 - - C16 [2] ZI/O 0PIO3_4 — General-purpose digital input/output pin.

I1PDM_DATA01 — PDM data input for DMIC channels 0 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_RTS_SCL_SSEL1 — Flexcomm 0: USART

request-to-send, I2C clock, SPI slave select 1.

PIO3_5 - - C14 [2] ZI/O 0PIO3_5 — General-purpose digital input/output pin.

I1PDM_DATA23 — PDM data input for DMIC channels 2 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_SSEL2 — Flexcomm 0: SPI slave select 2.

PIO3_6 - - C13 [2] ZI/O 0PIO3_6 — General-purpose digital input/output pin.

I1PDM_DATA45 — PDM data input for DMIC channels 4 and

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC0_SSEL3 — Flexcomm 0: SPI slave select 3.

PIO3_7 - - E10 [2] ZI/O 0PIO3_7 — General-purpose digital input/output pin.

I1PDM_DATA67 — PDM data input for DMIC channels 6 and

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 39 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO3_8 - - C10 [2] ZI/O 0PIO3_8 — General-purpose digital input/output pin.

O1SD1_CLK — SD/MMC1 clock.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT0 — 32-bit CTimer0 match output 0.

PIO3_9 - - B10 [2] ZI/O 0PIO3_9 — General-purpose digital input/output pin.

I/O 1 SD1_CMD — SD/MMC1 card command I/O.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT1 — 32-bit CTimer0 match output 1.

PIO3_10 - - C9 [2] ZI/O 0PIO3_10 — General-purpose digital input/output pin.

I/O 1 SD1_D[0] — SD/MMC1 interface data 0.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT2 — 32-bit CTimer0 match output 2.

PIO3_11 - - D9 [2] ZI/O 0PIO3_11 — General-purpose digital input/output pin.

I/O 1 SD1_D[1] — SD/MMC1 interface data 1.

2R — Reserved.

3R — Reserved.

O4CTIMER0_MAT3 — 32-bit CTimer0 match output 3.

PIO3_12 - - C8 [2] ZI/O 0PIO3_12 — General-purpose digital input/output pin.

I/O 1 SD1_D[2] — SD/MMC1 interface data 2.

2R — Reserved.

3R — Reserved.

I4CTIMER_INP0 — Capture input 0 to CTIMER input muxes.

PIO3_13 - - D5 [2] ZI/O 0PIO3_13 — General-purpose digital input/output pin.

I/O 1 SD1_D[3] — SD/MMC1 interface data 3.

2R — Reserved.

3R — Reserved.

I4CTIMER_INP1 — Capture input 1 to CTIMER input muxes.

PIO3_14 - - D10 [2] ZI/O 0PIO3_14 — General-purpose digital input/output pin.

I1SD1_WR_PRT — SD/MMC 1 write protect.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT0 — 32-bit CTimer3 match output 0.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 40 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO3_15 - - E9 [2] ZI/O 0PIO3_15 — General-purpose digital input/output pin.

I/O 1 SD1_D[4] — SD/MMC1 interface data 4.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT1 — 32-bit CTimer3 match output 1.

I/O 5 FC5_SCK — Flexcomm 5: USART, SPI, or I2S clock.

PIO3_16 - - E6 [2] ZI/O 0PIO3_16 — General-purpose digital input/output pin.

I/O 1 SD1_D[5] — SD/MMC1 interface data 5.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT2 — 32-bit CTimer3 match output 2.

I/O 5 FC5_TXD_SCL_MISO_WS — Flexcomm 5: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

PIO3_17 - - E5 [2] ZI/O 0PIO3_17 — General-purpose digital input/output pin.

I/O 1 SD1_D[6] — SD/MMC1 interface data 6.

2R — Reserved.

3R — Reserved.

O4CTIMER3_MAT3 — 32-bit CTimer3 match output 3.

I/O 5 FC5_RXD_SDA_MOSI_DATA — Flexcomm 5: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O

PIO3_18 - - D1 [2] ZI/O 0PIO3_18 — General-purpose digital input/output pin.

I/O 1 SD1_D[7] — SD/MMC1 interface data 7.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT0 — 32-bit CTimer4 match output 0.

I/O 5 FC5_CTS_SDA_SSEL0 — Flexcomm 5: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

PIO3_19 - - D2 [2] ZI/O 0PIO3_19 — General-purpose digital input/output pin.

I1SD1_CARD_DET_N — SD/MMC 1 card detect (active low).

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT1 — 32-bit CTimer4 match output 1.

I/O 5 MCLK — MCLK input or output for I2S and/or digital

microphone.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 41 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO3_20 - - C2 [2] ZI/O 0PIO3_20 — General-purpose digital input/output pin.

O1SD1_RESET_N — SD/MMC1 card hardware reset, active

low.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT2 — 32-bit CTimer4 match output 2.

PIO3_21 - - D8 [2] ZI/O 0PIO3_21 — General-purpose digital input/output pin.

O1SD1_VOLT — SD/MMC1 card regulator voltage control.

2R — Reserved.

3R — Reserved.

O4CTIMER4_MAT3 — 32-bit CTimer4 match output 3.

5R — Reserved.

O6GPIO_INT_BMAT — Output of the pin interrupt pattern

match engine.

PIO3_22 - - D6 [2] ZI/O 0PIO3_22 — General-purpose digital input/output pin.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC5_RTS_SCL_SSEL1 — Flexcomm 5: USART

request-to-send, I2C clock, SPI slave select 1.

PIO3_23/

CH5A

-- H12

[3] ZI/O 0PIO3_23/CH5A — General-purpose digital input/output pin.

Analog input 5A. Can optionally be paired with CH5B for

differential input on ADC channel 5.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC5_SSEL2 — Flexcomm 5: SPI slave select 2.

PIO3_24/

CH5B

-- E15

[3] ZI/O 0PIO3_24/CH5B — General-purpose digital input/output pin.

Analog input 5B. Can optionally be paired with CH5A for

differential input on ADC channel 5.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC5_SSEL3 — Flexcomm 5: SPI slave select 3.

PIO3_25 - - R9 [2] ZI/O 0PIO3_25 — General-purpose digital input/output pin.

I/O 1 FC6_SCK — Flexcomm 6: USART, SPI, or I2S clock.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 42 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO3_26 A8 - P9 [2] ZI/O 0PIO3_26 — General-purpose digital input/output pin.

I/O 1 FC6_TXD_SCL_MISO_WS — Flexcomm 6: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

PIO3_27 A7 - T8 [2] ZI/O 0PIO3_27 — General-purpose digital input/output pin.

I/O 1 FC6_RXD_SDA_MOSI_DATA — Flexcomm 6: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O

PIO3_28 - - R8 [2] ZI/O 0PIO3_28 — General-purpose digital input/output pin.

I/O 1 FC6_CTS_SDA_SSEL0 — Flexcomm 6: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

PIO3_29 - - P8 [2] ZI/O 0PIO3_29 — General-purpose digital input/output pin.

I/O 1 FC6_RTS_SCL_SSEL1 — Flexcomm 6: USART

request-to-send, I2C clock, SPI slave select 1.

PIO3_30 - - N9 [2] ZI/O 0PIO3_30 — General-purpose digital input/output pin.

I/O 1 FC6_SSEL2 — Flexcomm 6: SPI slave select 2.

PIO3_31 - - P7 [2] ZI/O 0PIO3_31 — General-purpose digital input/output pin.

I/O 1 FC6_SSEL3 — Flexcomm 6: SPI slave select 3.

PIO4_0 - - R13 [2] ZI/O 0PIO4_0 — General-purpose digital input/output pin.

I/O 1 FC7_SCK — Flexcomm 7: USART, SPI, or I2S clock.

2R — Reserved.

3R — Reserved.

I4FREQME_GPIO_CLK — Frequency Measure pin clock

input.

5R — Reserved.

6R — Reserved.

O7CLKOUT — Output of the CLKOUT function.

PIO4_1 - - T17 [2] ZI/O 0PIO4_1 — General-purpose digital input/output pin.

I/O 1 FC7_TXD_SCL_MISO_WS — Flexcomm 7: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

6R — Reserved.

I7CLKIN — Clock input.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 43 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO4_2 - - T16 [2] ZI/O 0PIO4_2 — General-purpose digital input/output pin.

I/O 1 FC7_RXD_SDA_MOSI_DATA — Flexcomm 7: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

PIO4_3 - - T3 [2] ZI/O 0PIO4_3 — General-purpose digital input/output pin.

I/O 1 FC7_CTS_SDA_SSEL0 — Flexcomm 7: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

PIO4_4 - - R2 [2] ZI/O 0PIO4_4 — General-purpose digital input/output pin.

I/O 1 FC7_RTS_SCL_SSEL1 — Flexcomm 7: USART

request-to-send, I2C clock, SPI slave select 1.

PIO4_5 - - P1 [2] ZI/O 0PIO4_5 — General-purpose digital input/output pin.

I/O 1 FC7_SSEL2 — Flexcomm 7: SPI slave select 2.

PIO4_6 - - P2 [2] ZI/O 0PIO4_6 — General-purpose digital input/output pin.

I/O 1 FC7_SSEL3 — Flexcomm 7: SPI slave select 3.

PIO4_7 - - P3 [2] ZI/O 0PIO4_7 — General-purpose digital input/output pin.

I/O 1 MCLK — MCLK input or output for I2S and/or digital

microphone.

PIO4_8 - - R4 [2] ZI/O 0PIO4_8 — General-purpose digital input/output pin.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC2_CTS_SDA_SSEL0 — Flexcomm 2: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

6R — Reserved.

O7CMP0_OUT — Analog comparator 0 output.

PIO4_9 - - R5 [2] ZI/O 0PIO4_9 — General-purpose digital input/output pin.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

5R — Reserved.

O6GPIO_INT_BMAT — Output of the pin interrupt pattern

match engine.

PIO4_10 - - R6 [2] ZI/O 0PIO4_10 — General-purpose digital input/output pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 44 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO7_24 - - T15 [2] ZI/O 0PIO7_24 — General-purpose digital input/output pin.

1R — Reserved.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC2_SCK — Flexcomm 2: USART, SPI, or I2S clock.

6R — Reserved.

PIO7_25 - - P12 [2] ZI/O 0PIO7_25 — General-purpose digital input/output pin.

I/O 1 FC1_SCK — Flexcomm 1: USART, SPI, or I2S clock.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 R — Reserved.

6R — Reserved.

PIO7_26 - - N12 [2] ZI/O 0PIO7_26 — General-purpose digital input/output pin.

I/O 1 FC1_TXD_SCL_MISO_WS — Flexcomm 1: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 R — Reserved.

6R — Reserved.

PIO7_27 - - R12 [2] ZI/O 0PIO7_27 — General-purpose digital input/output pin.

I/O 1 FC1_RXD_SDA_MOSI_DATA — Flexcomm 1: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 R — Reserved.

6R — Reserved.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 45 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PIO7_28 - - N10 [2] ZI/O 0PIO7_28 — General-purpose digital input/output pin.

I/O 1 FC1_CTS_SDA_SSEL0 — Flexcomm 1: USART

clear-to-send, I2C data I/O, SPI Slave Select 0.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 R — Reserved.

6R — Reserved.

PIO7_29 - - R10 [2] ZI/O 0PIO7_29 — General-purpose digital input/output pin.

I/O 1 FC1_RTS_SCL_SSEL1 — Flexcomm 1: USART

request-to-send, I2C clock, SPI slave select 1.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 R — Reserved.

6R — Reserved.

PIO7_30 - - P10 [2] ZI/O 0PIO7_30 — General-purpose digital input/output pin.

I/O 1 FC1_SSEL2 — Flexcomm 1: SPI slave select 2.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC2_TXD_SCL_MISO_WS — Flexcomm 2: USART

transmitter, I2C clock, SPI master-in/slave-out data I/O, I2S

word select/frame.

6R — Reserved.

PIO7_31 - - T4 [2] ZI/O 0PIO7_31 — General-purpose digital input/output pin.

I/O 1 FC1_SSEL3 — Flexcomm 1: SPI slave select 3.

2R — Reserved.

3R — Reserved.

4R — Reserved.

I/O 5 FC2_RXD_SDA_MOSI_DATA — Flexcomm 2: USART

receiver, I2C data I/O, SPI master-out/slave-in data, I2S data

I/O.

6R — Reserved.

PMIC_I2C_SCL - E16 F4 [4] Z O - I2C clock. Used for communication with an off-chip PMIC, if

present. It is not an open drain pin.

PMIC_I2C_SDA - F16 F3 [4] Z I/O - I2C data. Used for communication with an off-chip PMIC, if

present. It is not an open drain pin.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

_vsus , Table 5 Table 5

Product data sheet Rev. 1.7 — 20 January 2021 46 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

PMIC_IRQ_N - A15 F5 [4] Z I - Interrupt input, active low logic. Used with an off-chip PMIC, if

present.

PMIC_MODE0 - C15 D3 [4] O O - Power mode control output to an off-chip PMIC, if present.

Value is controlled by the PDRUNCFG and PDSLEEPCFG

registers. Reset state is 0.

PMIC_MODE1 - B16 E4 [4] O O - Power mode control output to an off-chip PMIC, if present.

Value is controlled by the PDRUNCFG and PDSLEEPCFG

registers. Reset state is 0.

RESETN K10 B15 C4 - I - External reset input: A LOW on this pin resets the device,

causing I/O ports and peripherals to take on their default

states, and the boot code to execute. Wakes up the part from

deep power-down mode.

RTCXIN - B17 A2 - - - RTC oscillator input. Selectable on-chip crystal load

capacitors are available for RTC oscillator. Please refer to UM

for further details.

RTCXOUT - A17 B3 - - - RTC oscillator input. Selectable on-chip crystal load

capacitors are available for RTC oscillator. Please refer to UM

for further details.

USB1_DM B9 T17 T1 - I/O - USB1 bidirectional D- line.

USB1_DP B10 R17 U2 - I/O - USB1 bidirectional D+ line.

USB1_VBUS [6] - R16 T2 - I - VBUS pin (power on USB cable). 5 V tolerant pin when

supplies are present or when not present.

USB1_VDD3V3 C10 N16 K5 [5] - - - USB1 analog 3.3 V supply.

LDO_ENABLE H9 A16 C5 - - - When 1, enables the on-chip regulator to power core logic

through the VDDCORE pins. Tie low if an off-chip power

management IC (PMIC) is used to supply power to core logic.

This pin can not be left floating. 100K external pull-up or 10K

external pull-down is recommended. LDO_Enable is a

fail-safe pin. It must be driven high before VDD_AO1V8

supply comes up or at the same time.

VDD_AO1V8 L11 C13;

D13

B2; D4 [5] - - - Supply 1.8 V supply for “always on” features. This includes

the RTC, RESETN, LDO_ENABLE, PMIC_IRQ_N,

PMIC_MODE0, and PMIC_MODE1. See Table 5

VDDIO_0 B8;

D7;

E7;

F2;

G3;

F5; H5;

K5; M5;

N6; N8;

N10

J12;

J13;

K12;

M10;

M12;

[5] - - - Single 1.8 V to 3.3 V power supply for GPIOs defined as

belonging to the VDDIO_0 group. VDDIO_0, VDDIO_1, and

VDDIO_2 may be supplied at different voltage levels as

needed by the application.

VDDIO_0 supplies the following port pins: PIO0_0 to

PIO0_13; PIO1_11 to PIO1_29; and PIO2_12 to PIO2_23.

See Table 5

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

e Table 5 Table 5 Secﬁon 1 ‘Power Seguencing"

Product data sheet Rev. 1.7 — 20 January 2021 47 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

VDDIO_1 E9;

J8;

E6; E8;

E10;

H13;

H14;

K13;

L14

F10;

F11;

F6; F7;

F9; J5;

[5] - - - Single 1.8 V to 3.3 V power supply for GPIOs defined as

belonging to the VDDIO_1 group. VDDIO_0, VDDIO_1, and

VDDIO_2 may be supplied at different voltage levels as

needed by the application.

VDDIO_1 supplies the following port pins: PIO0_14 to

PIO0_31; PIO1_0 to PIO1_10; PIO2_24 to PIO2_31;

PMIC_I2C_SCL and PMIC_I2C_SDA. See Ta b l e 5

VDDIO_2 - N12;

P11;

P12

M7; M8 [5] - - - Single 1.8 V to 3.3 V power supply for GPIOs defined as

belonging to the VDDIO_2 group. VDDIO_0, VDDIO_1, and

VDDIO_2 may be supplied at different voltage levels as

needed by the application. VDDIO_2 supplies the following

port pins: PIO1_30 to PIO1_31 and PIO2_0 to PIO2_11. See

Table 5

VDD1V8 A9;

K2;

L10;

D5;

G8;

H10;

H11;

J10

B11;

C16;

C17;

E15;

F13;

G14;

L4;

R15

E8;

J14;

H6; G6;

H7; J7;

[5] - - - 1.8 V supply voltage for on-chip analog functions other than

the ADC and comparator.

VDDA_ADC1V8 [7] E4 H13 [5] - - - 1.8 V analog supply voltage for ADC and comparator.

VDDA_BIAS [7] C4 E12 [5] - - - Bias for ADC and comparator. VDD_BIAS must equal to the

highest VDDIO rail voltage used for the ADC input channel or

comparator inputs.

VDDCORE A10;

C1;

E8;

F1;

F6;

F7;

G2;

G7;

G10;

G11

C5; D9;

F14;

J4;

J14;

P9; R5;

R14

G9;

H10;

H8; H9;

J10;

J11; J8;

J9;

K10;

K8; K9;

[5] - - - Power supply for core logic. May be supplied from the internal

LDO or externally by an off-chip power management IC

(PMIC). An external filter capacitor is always required on

these pins, see Section 13.2 “Power Sequencing”

VREFN [7] C2 G12 - - - ADC negative reference voltage.

VREFP [7] D2 F12 [5] - - - ADC positive reference voltage.

VDD1V8_1 G9 A13 F8 [5] - - - 1.8 V supply voltage for OTP during active mode. In

deep-sleep mode, this pin can be powered off to conserve

additional current (~ 65 uA). VDD1V8_1 must be stable

before performing any OTP related functions.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 48 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[1] Z = high impedance; pull-up or pull-down disabled. AI = analog input. I = input. O = output. I/O = input/output. Reset state reflects the pin

state at reset without boot code operation. For pin states in the different power modes.

[2] Pad with programmable glitch filter; provides digital I/O functions with TTL levels and hysteresis; normal drive strength. See Figure 31.

[3] Pin providing standard digital I/O functions with configurable modes, configurable hysteresis, and analog input. See Figure 31.

VSS A1;

A6;

A11;

B6;

D6;

E6;

F8;

F11;

G6;

J9;

J11;

L1;

D5;

D15;

E12;

E14;

F7;

F11;

G6;

G12;

H8; H9;

H10;

J8;

J10;

K8; K9;

K10;

L6;

L12;

M7;

M11;

M13;

N14;

P13

A1;

A17;

C11;

C15;

C3; C7;

E11;

E7;

G10;

G11;

G13;

G14;

G15;

G3;

G4;

G5;

G7;

G8;

H11;

K11;

K4; K7;

L10;

L11;

L12;

L13;

L14;

L15;

L3; L4;

L5; L6;

L7; L8;

M11;

N11;

N7;

P11;

R11;

R15;

R3; R7;

U1;

U17

- - - Ground.

VSSA [7] C3,

D12

D7;

D11

- - - Analog ground.

XTALIN K9 B14 B4 - - - Main oscillator input. USB ISP can only boot with external

crystal oscillator of 24 MHz.

XTALOUT L9 B13 A4 - - - Main oscillator output. USB ISP can only boot with external

crystal oscillator of 24 MHz.

Table 4. Pin description …continued

Symbol

114-pin, WLCSP

176-pin, VFBGA

249-pin, FOWLP

Reset state [1]

Type

Function #

Description

Product data sheet Rev. 1.7 — 20 January 2021 49 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[4] These pins are intended for connection to an off-chip power management IC (PMIC) if such a device is used to supply power to core

logic to this device. These pins may be used for other purposes if the on-chip regulator is used to supply power to core logic.

[5] See Section 13.1 “General operating conditions” for specification of actual allowable voltage ranges.

[6] On WLCSP114 package, USB ISP mode is not supported. VBUS pin is not available on the WLCSP114 package. To detect VBUS

connection, user can connect a GPIO pin to the USB connector's VBUS. When a rising edge occurs on the GPIO pin, software should

set bit 10 (FORCE_VBUS) and bit 16 (DCON) in the DEVCMDSTAT register.

[7] On the WLCSP package, VDDA_ADC1V8 is internally connected to VDD1V8 pin; VDDA_BIAS is internally connected to VDDIO_0;

VREFP is internally connected to VDD1V8; VREFN is internally connected to VSS; VSSA is internally connected to VSS.

Table 6

Product data sheet Rev. 1.7 — 20 January 2021 50 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

8. Power Supply for pins

Tabl e 6 shows the GPIOs belonging to the specific VDDIO groups and VDD_AO1V8 domain. Each

VDDIO supply pin may be supplied at different voltage levels as needed by the application and can

be powered between 1.71 V to 3.6 V.

Note: Please refer to Hardware Development Guide for the RT600 Processor on nxp.com.

This guide provides information about board layout recommendations and design

checklists to ensure first-pass success and to avoid problems with board bring-up.

Table 5. Power Supply for pins

Pin GPIO pins

VDDIO_0 PIO0_0 to PIO0_13

PIO1_11 to PIO1_29

PIO2_12 to PIO2_23

PIO3_25 to PIO3_31

PIO4_0 to PIO4_10

PIO7_24 to PIO7_31

VDDIO_1 PIO0_14 to PIO0_31

PIO1_0 to PIO1_10

PIO2_24 to PIO2_31

PIO3_0 to PIO3_24

PMIC_I2C_SCL

PMIC_I2C_SDA

VDDIO_2 PIO1_30 to PIO1_31

PIO2_0 to PIO2_11

VDD_AO1V8 RESETN

LDO_ENABLE

PMIC_IRQ_N

PMIC_MODE0 and PMIC_MODE1

Table 6 Default stale,

Product data sheet Rev. 1.7 — 20 January 2021 51 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

9. Termination of unused pins

Tabl e 6 shows how to terminate pins that are not used in the application. In many cases,

unused pins can be left unconnected since pins are default high Z state or can be

configured correctly by software to minimize the overall power consumption of the part.

Unused pins with GPIO function should be configured as outputs set to LOW with their

internal pull-up disabled. To configure a GPIO pin as output and drive it LOW, select the

GPIO function in the IOCON register, select output in the GPIO DIR register, and write a 0

to the GPIO PORT register for that pin. Disable the pull-up in the pin’s IOCON register.

In addition, it is recommended to configure all GPIO pins that are not bonded out on

smaller packages as outputs driven LOW with their internal pull-up disabled.

[1] Z = Input, pull-up, and pull-down disabled; I = Input; O = Output

9.0.1 Pin states in different power modes

[1] Default and programmed pin states are retained in sleep and deep-sleep.

Table 6. Termination of unused pins

Pin Default state[1] Recommended termination of unused pins

All PIOn pins I; Z Leave unconnected.

PMIC_I2C_SCL/SDA Z Leave unconnected.

PMIC_IRQ_N I; Z Tie high if not used in the system.

PMIC_MODEn O Leave unconnected.

RESETN I Tie high if not used in the system.

RTCXIN I Tie to ground.

RTCXOUT - Leave unconnected.

USB1_DM/DP - Leave unconnected.

USB1_VBUS - Leave unconnected.

USB1_VDD3V3 - Leave unconnected.

VDD_AO1V8 - Tie to 1.8V power.

VDD_1V8 - Tie to 1.8V power.

VDD_1V8_1 - Tie to 1.8V power during active. Can be powered off during deep sleep mode to

reduce current consumption by approximately 65 uA.

VDDA_ADC1V8 - Tie to 1.8V power.

VDDA_BIAS - Tie to 1.8 V power.

VREFN - Tie to VSS.

VREFP - Tie to VDDA_ADC1V8

VSSA - Tie to VSS.

XTALIN I Tie to ground.

XTALOUT - Leave unconnected.

Table 7. Pin states in different power modes

Pin Active Sleep Deep-sleep Deep power-down

All PIOn pins As configured in IOCON[1]. Default is Z (input, pull-up, and pull-down disable)

PMIC_MODE0/1 00 00

Semion 10.12.1 Figure 3

Product data sheet Rev. 1.7 — 20 January 2021 52 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10. Functional description

10.1 Architectural overview

The ARM Cortex-M33 includes two AHB-Lite buses, the system bus and the C-code bus.

The use of two core buses allows for simultaneous operations if concurrent operations

target different devices.

A multi-layer AHB matrix connects the CPU buses and other bus masters to peripherals in

a flexible manner that optimizes performance by allowing peripherals on different slaves

ports of the matrix to be accessed simultaneously by different bus masters. More

information on the multilayer matrix can be found in Section 10.12.1. Connections in the

multilayer matrix are shown in Figure 3. Note that while the AHB bus itself supports word,

halfword, and byte accesses, not all AHB peripherals need or provide that support.

10.2 Arm Cortex-M33 processor

The Cortex-M33 is a general purpose 32-bit microprocessor, which offers high

performance and very low power consumption. The Cortex-M33 offers an instruction set

based on Thumb®-2, low interrupt latency, interruptible/continuable multiple load and

store instructions, automatic state save and restore for interrupts, tightly integrated

interrupt controller, multiple core buses capable of simultaneous accesses, and a floating

point unit.

The RT600 includes the Armv8-M Security Extension that adds security through code and

data protection features.

Information about Cortex-M33 configuration options can be found in the user manual.

10.3 Arm Cortex-M33 integrated Floating Point Unit (FPU)

The FPU fully supports single-precision add, subtract, multiply, divide, multiply and

accumulate, and square root operations. It also provides conversions between fixed-point

and floating-point data formats, and floating-point constant instructions.

The FPU provides floating-point computation functionality that is compliant with the

ANSI/IEEE Std 754-2008, IEEE Standard for Binary Floating-Point Arithmetic, referred to

as the IEEE 754 standard.

10.4 Xtensa HiFi 4 advanced Audio Digital Signal Processor

The HiFi 4 Audio Engine is present on selected RT600 devices. The HiFi 4 is a highly

optimized audio processor geared for efficient execution of audio and voice codecs and

pre- and post-processing modules. It includes support for four 32x32-bit MACs, some

support for 72-bit accumulators, limited ability to support eight 32x16-bit MACs, and the

ability to issue two 64-bit loads per cycle. There is an floating point unit included, providing

up to four single-precision IEEE floating point MACs per cycle. The HiFi 4 Audio Engine is

a configuration option of the Xtensa LX6 processor. All HiFi 4 Audio Engine operations

can be used as intrinsics in standard C/C++ applications.

Information about HiFi 4 DSP configuration options can be found in the user manual.

Product data sheet Rev. 1.7 — 20 January 2021 53 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.5 Memory Protection Unit (MPU)

The Cortex-M33 processor has a memory protection unit (MPU) that provides fine grain

memory control, enabling applications to implement security privilege levels, separating

code, data and stack on a task-by-task basis. Such requirements are critical in many

embedded applications.

The MPU allows separating processing tasks by disallowing access to each other's data,

disabling access to memory regions, allowing memory regions to be defined as read-only

and detecting unexpected memory accesses that could potentially break the system.

The MPU separates the memory into distinct regions and implements protection by

preventing disallowed accesses. The MPU supports up to eight regions each of which can

be divided into eight subregions. Accesses to memory locations that are not defined in the

MPU regions, or not permitted by the region setting, will cause the Memory Management

Fault exception to take place.

10.6 Nested Vectored Interrupt Controller (NVIC) for Cortex-M33

The NVIC is an integral part of the Cortex-M33. The tight coupling to the CPU allows for

low interrupt latency and efficient processing of late arriving interrupts.

10.6.1 Features

•Controls system exceptions and peripheral interrupts.

•Supports up to 58 vectored interrupts.

•Eight programmable interrupt priority levels, with hardware priority level masking.

•Relocatable vector table.

•Non-Maskable Interrupt (NMI).

•Software interrupt generation.

10.6.2 Interrupt sources

Each peripheral device has one interrupt line connected to the NVIC but may have several

interrupt flags.

10.7 System Tick timer (SysTick)

The Arm Cortex-M33 includes a system tick timer (SysTick) that is intended to generate a

dedicated SYSTICK exception. The clock source for the SysTick can be the FRO or the

Cortex-M33 core clock.

10.8 PowerQuad Hardware Accelerator

The RT600 has a PowerQuad hardware accelerator for CMSIS DSP functions (fixed and

floating point unit) with support of SDK software API faster execution of ARM CMSIS

instruction set.The PowerQuad is a hardware accelerator targeting common calculations

in DSP applications. With the assistance of the PowerQuad, the Cortex-M33 can be freed

to perform other tasks. While the PowerQuad is executing the assigned computation task,

the CM33 can prepare the next PowerQuad task, resulting in a pipeline of PowerQuad

tasks.

Figure 4

Product data sheet Rev. 1.7 — 20 January 2021 54 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.9 On-chip static RAM

The RT600 supports 5 MB SRAM with separate bus master access for higher throughput

and individual power control for low-power operation.

10.10 On-chip ROM

The 128 kB on-chip ROM contains the boot loader and the following Application

Programming Interfaces (API):

•In-Application Programming (IAP) and In-System Programming (ISP).

•ROM-based USB drivers (HID, CDC, MSC, and DFU). Supports flash updates via

USB. USB ISP mode is not supported in WLCSP114 package.

•Supports booting from valid USART, SPI, I2C, Octal/Quad SPI, HS USB, SD/eMMC.

•Legacy, Single, and Dual image boot.

•OTP API for programming OTP memory.

•Random Number Generator (RNG) API.

10.11 OTP

The RT600 contains up to 16 kB byte of on-time-programmable memory used for part

configuration, key storage (as an alternative to PUF) and various other uses. The OTP

contains pre-programmed factory configuration data such as on-chip oscillator calibration

values, among other things. It may also be used by customer applications to configure

some details of device operation, code signature values, aspects of device security,

debug options, and boot options

10.12 Memory mapping

The RT600 incorporates several distinct memory regions. The APB peripheral area is 512

kB in size and is divided to allow for up to 64 peripherals.Each peripheral is allocated 4 kB

of space simplifying the address decoding. The registers incorporated into the CPU, such

as NVIC, SysTick, and sleep mode control, are located on the private peripheral bus.

The Arm Cortex-M33 processor has a single 4 GB address space.

10.12.1 AHB multilayer matrix

The RT600 uses a multi-layer AHB matrix to connect the CPU buses and other bus

masters to peripherals in a flexible manner that optimizes performance by allowing

peripherals that are on different slave ports of the matrix to be accessed simultaneously

by different bus masters. Figure 4 shows details of the available matrix connections.

Remark: Attempted accesses by the CM33 to unused spaces between assigned memory

and peripheral spaces generally cause an exception. For the HiFi4 this is not the case.

10.12.2 Memory Protection Unit (MPU)

The Cortex-M33 processor has a memory protection unit (MPU) that provides fine grain

memory control, enabling applications to implement security privilege levels, separating

code, data and stack on a task-by-task basis. Such requirements are critical in many

embedded applications.

Table 8 Figure 3 “Block diagram overview" Semion 10.125 “Device overview"

Product data sheet Rev. 1.7 — 20 January 2021 55 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

The MPU register interface is located on the private peripheral bus and is described in

detail in Cortex-M33 DGUG — ARM Cortex-M33 Devices Generic User Guide

10.12.3 TrustZone and Cortex-M33 busing on this device

The implementation of ARM TrustZone on this device involves using address bit 28 to

divide the address space into potential secure and non-secure regions. Address bit 28 is

not decoded in memory access hardware, so each physical location appears in two

places on whatever bus they are located on. Other hardware determines which kinds of

accesses (including non-secure callable) are actually allowed for any particular address.

In addition, the shared RAM is generally expected to be used for both code and data, in

different balance for different applications. Some applications may require a great deal of

code and little data, others may require most of the shared RAM to be used for data. For

this reason, the entire shared RAM appears on both the code bus and the data bus of the

Cortex-M33. Code can be located at addresses that are on the code bus, data can be

located at addresses that are on the data bus. As long as code and data are contained in

shared RAM that is connected on different AHB matrix slave ports, each can be accessed

simultaneously on the appropriate bus.

Tabl e 8 shows the overall mapping of the code and data buses for secure and non-secure

accesses to various device resources. The block diagrams in Figure 3 “Block diagram

overview” may also be useful in understanding the memory map.

In addition to the fixed mapping of secure and non-secure spaces, “checker” hardware

present on all AHB matrix ports confirms the types of access allowed for each peripheral

or memory range (with a granularity of 32 memory ranges for each port). This is described

in more detail in RT6xx User Manual (please see RT6xx Trusted execution environment

chapter)

Remark: In the peripheral description chapters of this manual, only the native

(non-secure) base address is noted, secure base addresses can be found in this chapter

or created algorithmically where needed.

[1] The HiFi 4 accesses shared RAM via a separate connection, not using the AHB matrix.

[2] The size shown for peripherals spaces indicates the space allocated in the memory map, not the actual

space used by the peripheral.

[3] Some AHB and APB peripherals are not accessible to the HiFi 4.

[4] Selected areas of secure regions may be marked as non-secure callable.

10.12.4 Links to specific memory map descriptions and tables:

•Section 10.12.5 “Device overview”

Table 8. TrustZone and Cortex-M33 general mapping

Start address End address TrustZone CM-33 bus CM-33 usage

0x0000 0000 0x0FFF FFFF Non-secure Code Shared RAM, Boot ROM, OSPI memory mapped region.

0x1000 0000 0x1FFF FFFF Secure Code Same as above

0x2000 0000 0x2FFF FFFF Non-secure Data Shared RAM, CM33 access to HiFi 4 TCMs via inbound PIF.

Non-cacheable FlexSPI memory mapped region for DSP only.

0x3000 0000 0x3FFF FFFF Secure Data Same as above

0x4000 0000 0x4FFF FFFF Non-secure Data AHB and APB peripherals.

0x5000 0000 0x5FFF FFFF Secure Data Same as above

Section 10.126 “Cortex-M33 Memory overview" Section 10.127 “Shared RAM detail" Section 10.128 “APB Qerigherals" Section 10.129 “AHB gerigherals" Section 10.12.10 “HiFi 4 memoq mag"

Product data sheet Rev. 1.7 — 20 January 2021 56 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•Section 10.12.6 “Cortex-M33 Memory overview”

•Section 10.12.7 “Shared RAM detail”

•Section 10.12.8 “APB peripherals”

•Section 10.12.9 “AHB peripherals”

•Section 10.12.10 “HiFi 4 memory map”

Table 9 Section 1012.7 access. See Section 10.12.10 Section 10126 Section 1012.6 7 Section 10.12.10 7 Section 1012.7 7 Section 1012.6 Section 1012.6 Section 1012.7 access. See Section 10.12.10 Section 1012.6 Section 10.12.10 Section 10.12.10 Section 10.12 6 Section 10.12.10 7 Section 1012.7 7 Section 1012.6 Section 1012.6 Section 10.12.10 Section 10.1 a Section 10.12.10 7 Section 10129 Section 10.12.10 7 Section 1012.8 Section 1012.9

Product data sheet Rev. 1.7 — 20 January 2021 57 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.5 Device overview

The RT600 incorporates several distinct memory regions. Tab l e 9 gives a simplified view

of the overall map of the entire address space from the user program viewpoint following

reset. The figure indicates the main address regions and how (or whether) they related to

both the Cortex-M33 and the HiFi 4.

[1] The HiFi 4 accesses shared RAM via a separate connection, not using the AHB matrix.

[2] Access to the FlexSPI memory space can be enabled or disabled for the CM33 and the HiFi 4.

Table 9. Device overview memory map

Start addr End addr Size Cortex-M33 function HiFi 4 function

0x0000 0000 0x0047 FFFF 4.5 MB Shared RAM via the CM33 code bus (non-secure

access). See Section 10.12.7.

Shared RAM - cacheable

access. See Section 10.12.10.

[1]

0x0300 0000 0x0303 FFFF 256 KB Boot ROM (non-secure access). See

Section 10.12.6

0x0800 0000 0x0FFF FFFF 128 MB FlexSPI memory mapped space with cache and

on-the-fly AES decryption (non-secure access).

See Section 10.12.6. [2]

FlexSPI memory mapped

space, cacheable. See

Section 10.12.10. [2]

0x1000 0000 0x1047 FFFF 4.5 MB Shared RAM via the CM33 code bus (secure

access). See Section 10.12.7. [3]

0x1300 0000 0x1303 FFFF 256 KB Boot ROM (secure access). See Section 10.12.6 -

0x1800 0000 0x1FFF FFFF 128 MB FlexSPI memory mapped space with cache and

on-the-fly AES decryption (secure access). See

Section 10.12.6.

0x2000 0000 0x2047 FFFF 4.5 MB Shared RAM via the CM33 data bus (non-secure

access). See Section 10.12.7.

Shared RAM - non-cacheable

access. See Section 10.12.10.

[1]

0x2400 0000 0x2400 FFFF 64 KB Cortex-M33 access to HiFi 4 data TCM via inbound

PIF (non-secure access). See Section 10.12.6.

HiFi 4 data TCM - 4

interleaved banks. See

Section 10.12.10.

0x2402 0000 0x2402 FFFF 64 KB Cortex-M33 access to HiFi 4 instruction TCM via

inbound PIF (non-secure access). See

Section 10.12.6.

HiFi 4 instruction TCM. See

Section 10.12.10.

0x2800 0000 0x2FFF FFFF 128 MB - FlexSPI memory mapped

space, non-cacheable. See

Section 10.12.10. [2]

0x3000 0000 0x3047 FFFF 4.5 MB Shared RAM via the CM33 data bus (secure

access). See Section 10.12.7. [3]

0x3400 0000 0x3400 FFFF 64 KB Cortex-M33 access to HiFi 4 data TCM via inbound

PIF (secure access). See Section 10.12.6.

0x3402 0000 0x3402 FFFF 64 KB Cortex-M33 access to HiFi 4 instruction TCM via

inbound PIF (secure access). See Section 10.12.6.

HiFi 4 instruction TCM. See

Section 10.12.10.

0x4000 0000 0x4003 FFFF 256 KB

[4]

APB peripherals (non-secure access). See

Section 10.12.8.

APB peripherals. See

Section 10.12.10. [5]

0x4010 0000 0x4015 FFFF 400 KB

[4]

AHB peripherals (non-secure access). See

Section 10.12.9.

AHB peripherals. See

Section 10.12.10. [5]

0x5000 0000 0x5003 FFFF 256 KB

[4]

APB peripherals (secure access). See

Section 10.12.8.

0x5010 0000 0x5015 FFFF 400 KB

[4]

AHB peripherals (secure access). See

Section 10.12.9.

Product data sheet Rev. 1.7 — 20 January 2021 58 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[3] Selected areas of secure regions may be marked as non-secure callable.

[4] The size shown for peripheral spaces indicates the space allocated in the memory map, not the actual

space used by the peripheral.

[5] Some AHB and APB peripherals are not accessible to the HiFi 4.

Table 10 Section 10.125 0,

Product data sheet Rev. 1.7 — 20 January 2021 59 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.6 Cortex-M33 Memory overview

Tabl e 1 0 gives a more detailed memory map as seen by the Cortex-M33. The purpose of

the four address spaces for the shared RAMs is outlined at the beginning of this chapter.

The details of which shared RAM regions are on which AHB matrix slave ports can be

seen here. Further details given in Section 10.12.6.

[1] Gaps between AHB matrix slave ports are not shown.

[2] Details of this space may be found in Section 10.12.8 “APB peripherals”.

[3] Details of this space may be found in Section 10.12.9 “AHB peripherals”.

Table 10. Cortex-M33 overview memory map

AHB

port

Non-secure

start address

Non-secure

end address

Secure start

address

Secure end

address

Function [1]

2 0x0000 0000 0x0000 FFFF 0x1000 0000 0x1000 FFFF Shared RAM on CM33 code bus, partitions 0 to 1.

3 0x0001 0000 0x0001 FFFF 0x1001 0000 0x1001 FFFF Shared RAM on CM33 code bus, partitions 2 to 3.

4 0x0002 0000 0x0003 FFFF 0x1002 0000 0x1003 FFFF Shared RAM on CM33 code bus, partitions 4 to 7.

5 0x0004 0000 0x0007 FFFF 0x1004 0000 0x1007 FFFF Shared RAM on CM33 code bus, partitions 8 to 11.

6 0x0008 0000 0x000F FFFF 0x1008 0000 0x100F FFFF Shared RAM on CM33 code bus, partitions 12 to 15.

7 0x0010 0000 0x001F FFFF 0x1010 0000 0x101F FFFF Shared RAM on CM33 code bus, partitions 16 to 19.

8 0x0020 0000 0x002F FFFF 0x1020 0000 0x102F FFFF Shared RAM on CM33 code bus, partitions 20 to 23.

9 0x0030 0000 0x003F FFFF 0x1030 0000 0x103F FFFF Shared RAM on CM33 code bus, partitions 24 to 27.

10 0x0040 0000 0x0047 FFFF 0x1040 0000 0x1047 FFFF Shared RAM on CM33 code bus, partitions 28 to 29.

0 0x0300 0000 0x0303 FFFF 0x1300 0000 0x1303 FFFF Boot ROM

1 0x0800 0000 0x0FFF FFFF 0x1800 0000 0x1FFF FFFF FlexSPI memory mapped space with cache and

on-the-fly AES decryption.

2 0x2000 0000 0x2000 FFFF 0x3000 0000 0x3000 FFFF Shared RAM on CM33 data bus, partitions 0 to 1.

3 0x2001 0000 0x2001 FFFF 0x3001 0000 0x3001 FFFF Shared RAM on CM33 data bus, partitions 2 to 3.

4 0x2002 0000 0x2003 FFFF 0x3002 0000 0x3003 FFFF Shared RAM on CM33 data bus, partitions 4 to 7.

5 0x2004 0000 0x2007 FFFF 0x3004 0000 0x3007 FFFF Shared RAM on CM33 data bus, partitions 8 to 11.

6 0x2008 0000 0x200F FFFF 0x3008 0000 0x300F FFFF Shared RAM on CM33 data bus, partitions 12 to 15.

7 0x2010 0000 0x201F FFFF 0x3010 0000 0x301F FFFF Shared RAM on CM33 data bus, partitions 16 to 19.

8 0x2020 0000 0x202F FFFF 0x3020 0000 0x302F FFFF Shared RAM on CM33 data bus, partitions 20 to 23.

9 0x2030 0000 0x203F FFFF 0x3030 0000 0x303F FFFF Shared RAM on CM33 data bus, partitions 24 to 27.

10 0x2040 0000 0x2047 FFFF 0x3040 0000 0x3047 FFFF Shared RAM on CM33 data bus, partitions 28 to 29.

11 0x2400 0000 0x240F FFFF 0x3400 0000 0x340F FFFF HiFi 4 inbound PIF. Allows AHB access to HiFi 4

Instruction and Data TCMs.

12 0x4000 0000 0x4001 FFFF 0x5000 0000 0x5001 FFFF AHB to APB bridge 0 [2]

0x4002 0000 0x4003 FFFF 0x5002 0000 0x5003 FFFF AHB to APB bridge 1 [2]

13 0x4010 0000 0x4011 FFFF 0x5010 0000 0x5011 FFFF AHB peripherals [3]

14 0x4012 0000 0x4012 FFFF 0x5012 0000 0x5012 FFFF AHB peripherals [3]

15 0x4013 0000 0x4013 FFFF 0x5013 0000 0x5013 FFFF AHB peripherals [3]

16 0x4014 0000 0x4014 FFFF 0x5014 0000 0x5014 FFFF AHB peripherals [3]

17 0x4015 0000 0x4015 FFFF 0x5015 0000 0x5015 FFFF AHB peripherals [3]

Table 11 Table 11 Seclion 10.123 Table 12

Product data sheet Rev. 1.7 — 20 January 2021 60 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.7 Shared RAM detail

Tabl e 11 reflects both the Cortex-M33 and DSP views of the RAM partitions and address.

The AHB matrix port is only relevant to the Cortex-M33 because the DSP accesses these

RAMs via a separate bus.

The partitions shown in Tab le 11 are mirrored in all four shared RAM address regions for

the Cortex-M33. The purpose of those regions is outlined in Section 10.12.3, while

Tabl e 1 2 gives the base addresses for the four regions.

A variety of shared RAM partition sizes are provided to allow more flexibility in assigning

the uses of those spaces. For each application, shard RAM usage should be planned to

minimize collision of accesses by the two buses of the Cortex-M33, as well as other bus

masters, including DMA controllers and the HiFi 4.

A best case would be if each shared RAM partition is accessed by only one master at any

particular time, “ownership” being passed to another master (for instance) when a buffer is

filled from a peripheral, a block of data is processed by an algorithm, etc.

To summarize, access collisions can occur under the following conditions.

•On the AHB matrix: when two AHB masters access a resource on the same slave port

at the same time. AHB masters include the HiFi 4 when it is using the AHB matrix, not

when it is accessing shared RAM.

•HiFi 4 accessing shared RAM: when the HiFi 4 and an AHB master access the same

shared RAM partition at the same time. Note that in this case, the access collision

happens at the partition, not at the slave port. Since there are multiple partitions for

each slave port, this allows even more opportunity to avoid collisions.

Table 11. Shared RAM memory map: offsets for all types of shared memory accesses

AHB port Partition Start offset End offset Size

2 0 0x00 0000 0x00 7FFF 32 KB

1 0x00 8000 0x00 FFFF 32 KB

3 2 0x01 0000 0x01 7FFF 32 KB

3 0x01 8000 0x01 FFFF 32 KB

4 4 0x02 0000 0x02 7FFF 32 KB

5 0x02 8000 0x02 FFFF 32 KB

6 0x03 0000 0x03 7FFF 32 KB

7 0x03 8000 0x03 FFFF 32 KB

5 8 0x04 0000 0x04 FFFF 64 KB

9 0x05 0000 0x05 FFFF 64 KB

10 0x06 0000 0x06 FFFF 64 KB

11 0x07 0000 0x07 FFFF 64 KB

6 12 0x08 0000 0x09 FFFF 128 KB

13 0x0A 0000 0x0B FFFF 128 KB

14 0x0C 0000 0x0D FFFF 128 KB

15 0x0E 0000 0x0F FFFF 128 KB

Section 10.12.10.1 Section10.12.10.1

Product data sheet Rev. 1.7 — 20 January 2021 61 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

7 16 0x10 0000 0x13 FFFF 256 KB

17 0x14 0000 0x17 FFFF 256 KB

18 0x18 0000 0x1B FFFF 256 KB

19 0x1C 0000 0x1F FFFF 256 KB

8 20 0x20 0000 0x23 FFFF 256 KB

21 0x24 0000 0x27 FFFF 256 KB

22 0x28 0000 0x2B FFFF 256 KB

23 0x2C 0000 0x2F FFFF 256 KB

9 24 0x30 0000 0x33 FFFF 256 KB

25 0x34 0000 0x37 FFFF 256 KB

26 0x38 0000 0x3B FFFF 256 KB

27 0x3C 0000 0x3F FFFF 256 KB

10 28 0x40 0000 0x43 FFFF 256 KB

29 0x44 0000 0x47 FFFF 256 KB

Table 12. Base addresses for different types of shared memory accesses

Base address Cortex-M33 HiFi 4

0x0000 0000 Code bus - non-secure Cacheable (see Section 10.12.10.1)

0x1000 0000 Code bus - secure -

0x2000 0000 Data bus - non-secure Non-cacheable (see

Section 10.12.10.1)

0x3000 0000 Data bus - secure -

Table 11. Shared RAM memory map: offsets for all types of shared memory accesses

AHB port Partition Start offset End offset Size

Table 13

Product data sheet Rev. 1.7 — 20 January 2021 62 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.8 APB peripherals

Tabl e 1 3 provides details of the addresses for APB peripherals. APB peripherals have

both secure and non-secure access possibilities, and are accessible by the HiFi 4 unless

secured.

[1] Reset, clock, and system control functions are separated into 2 groups to allow the possibility of securing

group 0 while leaving group 1 unsecured.

Table 13. APB peripherals memory map

AHB

port

APB

bridge

Non-secure

base address

Secure

base address

Peripheral

12 0 0x4000 0000 0x5000 0000 RSTCTL0. Reset control group 0. [1]

0x4000 1000 0x5000 1000 CLKCTL0. Clock control group 0. [1]

0x4000 2000 0x5000 2000 SYSCTL0. System control group 0. [1]

0x4000 4000 0x5000 4000 IOCON. Pin function selection and pin control setup.

0x4000 6000 0x5000 6000 PUF. Physical unclonable function cryptographic key generation.

0x4000 E000 0x5000 E000 WWDT0 (Windowed watchdog timer 0).

0x4000 F000 0x5000 F000 Utick (Micro-tick timer).

1 0x4002 0000 0x5002 0000 RSTCTL1. Reset control group 1. [1]

0x4002 1000 0x5002 1000 CLKCTL1. Clock control group 1. [1]

0x4002 2000 0x5002 2000 SYSCTL1. System control group 1. [1]

0x4002 5000 0x5002 5000 GPIO pin interrupts (PINT).

0x4002 6000 0x5002 6000 Input multiplexing controls.

0x4002 8000 0x5002 8000 CT32B0 (standard counter/timer 0).

0x4002 9000 0x5002 9000 CT32B1 (standard counter/timer 1).

0x4002 A000 0x5002 A000 CT32B2 (standard counter/timer 2).

0x4002 B000 0x5002 B000 CT32B3 (standard counter/timer 3).

0x4002 C000 0x5002 C000 CT32B4 (standard counter/timer 4).

0x4002 D000 0x5002 D000 MRT (Multi-Rate Timer).

0x4002 E000 0x5002 E000 WWDT1 (Windowed watchdog timer 1).

0x4002 F000 0x5002 F000 Frequency measure unit.

0x4003 0000 0x5003 0000 RTC & Wake-up timer.

0x4003 6000 0x5003 6000 I3C interface.

0x4003 7000 0x5003 7000 Reserved.

Table 14

Product data sheet Rev. 1.7 — 20 January 2021 63 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.9 AHB peripherals

Tabl e 1 4 provides details of the addresses for AHB peripherals. AHB peripherals have

both secure and non-secure access possibilities. Some AHB matrix ports are accessible

by the HiFi 4 (for peripherals that are not secure), some are accessible only by the

Cortex-M33.

Table 14. AHB peripheral memory map

AHB

port

Non-secure

base address

Secure

base address

Accessible

by HiFi 4?

Peripheral

13 0x4010 0000 0x5010 0000 Yes High Speed GPIO (general purpose I/O for port pins that are not

selected for some other function by IOCON).

0x4010 4000 0x5010 4000 DMA0 registers.

0x4010 5000 0x5010 5000 DMA1 registers.

0x4010 6000 0x5010 6000 Flexcomm Interface 0.

0x4010 7000 0x5010 7000 Flexcomm Interface 1.

0x4010 8000 0x5010 8000 Flexcomm Interface 2.

0x4010 9000 0x5010 9000 Flexcomm Interface 3.

0x4010 F000 0x5010 F000 Debug mailbox.

0x4011 0000 0x5011 0000 Message Unit A (Cortex-M33 port).

0x4011 1000 0x5011 1000 Message Unit B (HiFi 4 port).

0x4011 2000 0x5011 2000 Semaphore.

0x4011 3000 0x5011 3000 OS Event Timer 0 (for access by Cortex-M33).

0x4011 4000 0x5011 4000 OS Event Timer 1 (for access by HiFi 4).

14 0x4012 0000 0x5012 0000 Yes CRC Engine.

0x4012 1000 0x5012 1000 D-MIC (8 channel PDM digital microphone interface)

0x4012 2000 0x5012 2000 Flexcomm Interface 4.

0x4012 3000 0x5012 3000 Flexcomm Interface 5.

0x4012 4000 0x5012 4000 Flexcomm Interface 6.

0x4012 6000 0x5012 6000 Flexcomm Interface 14 (High Speed SPI).

0x4012 7000 0x5012 7000 Flexcomm Interface 15 (PMIC I2C).

15 0x4013 0000 0x5013 0000 Yes OTP Controller (One Time Programmable factory and user settings).

0x4013 4000 0x5013 4000 FlexSPI and OTFAD registers.

0x4013 5000 0x5013 5000 PMC (PMU control).

0x4013 6000 0x5013 6000 SDIO0 registers.

0x4013 8000 0x5013 8000 Random Number Generator.

0x4013 9000 0x5013 9000 ACMP0 (comparator).

0x4013 A000 0x5013 A000 ADC0.

0x4013 B000 0x5013 B000 HS USB PHY registers.

16 0x4014 0000 0x5014 0000 No HS USB RAM interface.

0x4014 4000 0x5014 4000 HS USB device registers.

0x4014 5000 0x5014 5000 HS USB host registers.

0x4014 6000 0x5014 6000 SCTimer/PWM.

0x4014 8000 0x5014 8000 Security Control registers (AHB_SECURE_CTRL).

Product data sheet Rev. 1.7 — 20 January 2021 64 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

17 0x4015 0000 0x5015 0000 No PowerQuad coprocessor.

0x4015 1000 0x5015 1000 Casper coprocessor.

0x4015 2000 0x5015 2000 Casper RAM interface.

0x4015 4000 0x5015 4000 Secure HS GPIO (alternate 32-bit GPIO facility that can be secured

separately from the main GPIO).

0x4015 8000 0x5015 8000 Hash-AES registers.

Table 14. AHB peripheral memory map …continued

AHB

port

Non-secure

base address

Secure

base address

Accessible

by HiFi 4?

Peripheral

Table 15 11,

Product data sheet Rev. 1.7 — 20 January 2021 65 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.12.10 HiFi 4 memory map

Tabl e 1 5 provides a detailed memory map from the viewpoint of the HiFi 4.

Table 15. HiFi 4 overview memory map

Cacheable start

address [1]

Cacheable end

address [1]

Non-cacheable

start address [1]

Non-cacheable

end address [1]

Function Size AHB

port

0x0000 0000 0x0000 7FFF 0x2000 0000 0x2000 7FFF Shared RAM partition 0. 32 KB 2 [2]

0x0000 8000 0x0000 FFFF 0x2000 8000 0x2000 FFFF Shared RAM partition 1. 32 KB

0x0001 0000 0x0001 7FFF 0x2001 0000 0x2001 7FFF Shared RAM partition 2. 32 KB 3 [2]

0x0001 8000 0x0001 FFFF 0x2001 8000 0x2001 FFFF Shared RAM partition 3. 32 KB

0x0002 0000 0x0002 7FFF 0x2002 0000 0x2002 7FFF Shared RAM partition 4. 32 KB 4 [2]

0x0002 8000 0x0002 FFFF 0x2002 8000 0x2002 FFFF Shared RAM partition 5. 32 KB

0x0003 0000 0x0003 7FFF 0x2003 0000 0x2003 7FFF Shared RAM partition 6. 32 KB

0x0003 8000 0x0003 FFFF 0x2003 8000 0x2003 FFFF Shared RAM partition 7. 32 KB

0x0004 0000 0x0004 FFFF 0x2004 0000 0x2004 FFFF Shared RAM partition 8. 64 KB 5 [2]

0x0005 0000 0x0005 FFFF 0x2005 0000 0x2005 FFFF Shared RAM partition 9. 64 KB

0x0006 0000 0x0006 FFFF 0x2006 0000 0x2006 FFFF Shared RAM partition 10. 64 KB

0x0007 0000 0x0007 FFFF 0x2007 0000 0x2007 FFFF Shared RAM partition 11. 64 KB

0x0008 0000 0x0009 FFFF 0x2008 0000 0x2009 FFFF Shared RAM partition 12. 128 KB 6 [2]

0x000A 0000 0x000B FFFF 0x200A 0000 0x200B FFFF Shared RAM partition 13. 128 KB

0x000C 0000 0x000D FFFF 0x200C 0000 0x200D FFFF Shared RAM partition 14. 128 KB

0x000E 0000 0x000F FFFF 0x200E 0000 0x200F FFFF Shared RAM partition 15. 128 KB

0x0010 0000 0x0013 FFFF 0x2010 0000 0x2013 FFFF Shared RAM partition 16. 256 KB 7 [2]

0x0014 0000 0x0017 FFFF 0x2014 0000 0x2017 FFFF Shared RAM partition 17. 256 KB

0x0018 0000 0x001B FFFF 0x2018 0000 0x201B FFFF Shared RAM partition 18. 256 KB

0x001C 0000 0x001F FFFF 0x201C 0000 0x201F FFFF Shared RAM partition 19. 256 KB

0x0020 0000 0x0023 FFFF 0x2020 0000 0x2023 FFFF Shared RAM partition 20. 256 KB 8 [2]

0x0024 0000 0x0027 FFFF 0x2024 0000 0x2027 FFFF Shared RAM partition 21. 256 KB

0x0028 0000 0x002B FFFF 0x2028 0000 0x202B FFFF Shared RAM partition 22. 256 KB

0x002C 0000 0x002F FFFF 0x202C 0000 0x202F FFFF Shared RAM partition 23. 256 KB

0x0030 0000 0x0033 FFFF 0x2030 0000 0x2033 FFFF Shared RAM partition 24. 256 KB 9 [2]

0x0034 0000 0x0037 FFFF 0x2034 0000 0x2037 FFFF Shared RAM partition 25. 256 KB

0x0038 0000 0x003B FFFF 0x2038 0000 0x203B FFFF Shared RAM partition 26. 256 KB

0x003C 0000 0x003F FFFF 0x203C 0000 0x203F FFFF Shared RAM partition 27. 256 KB

0x0040 0000 0x0043 FFFF 0x2040 0000 0x2043 FFFF Shared RAM partition 28. 256 KB 10 [2]

0x0044 0000 0x0047 FFFF 0x2044 0000 0x2047 FFFF Shared RAM partition 29. 256 KB

0x2400 0000 0x2400 FFFF - - Data TCM - in 4 interleaved banks. 64 KB 11 [2]

0x2402 0000 0x2402 FFFF - - Instruction TCM (includes the

default vector table)

64 KB

- - 0x4000 0000 0x4001 FFFF AHB to APB bridge 0 128 KB 12

- - 0x4002 0000 0x4003 FFFF AHB to APB bridge 1 128 KB

- - 0x4010 0000 0x4011 FFFF AHB peripherals [3] 128 KB 13

- - 0x4012 0000 0x4012 FFFF AHB peripherals [3] 64 KB 14

- - 0x4013 0000 0x4013 FFFF AHB peripherals 64 KB 15

Table 15

Product data sheet Rev. 1.7 — 20 January 2021 66 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[1] This is a suggested configuration of cacheable and non-cacheable regions, See Section 10.12.10.1 below.

[2] The HiFi 4 does not use AHB to access this space.

[3] AHB peripherals on other AHB matrix ports are not accessible to the HiFi 4. See Section 10.12.9 “AHB

peripherals”.

10.12.10.1 Using cacheable and non-cacheable memory regions

The cacheable and non-cacheable regions indicated in the table above and elsewhere in

this chapter are recommended (not forced by hardware) in order to insure that the TCMs

are not in cacheable space. If this is not done, TCM accesses will use additional power

while providing no performance improvement. Cacheable and non-cacheable regions

may be user configured via software tools (e.g. the linker used to create HiFi 4 code), and

at run time via API calls.

The recommended configuration allows the user to control cache usage for the large

shared memory via the two logical address ranges that access the same physical

memories. By selecting the address for specific memory usage (as shown in Tab le 15 ),

the cache will, or will not, be used for that access.

For example, HiFi4 code may always be placed at cacheable addresses. Data that is

accessed as a long sequential stream (and therefore not useful to cache) may be placed

in non-cacheable addresses. Avoiding the cache when it is not needed will save power

and leave more cache space for operations that can take advantage of it.

In addition, cacheing certain areas, such as data that is altered through a different path

such as DMA, or peripheral registers, can cause improper operation.

10.13 System control

10.13.1 Clock sources

The RT600 supports three external and three internal clock sources:

•12 Mhz Free Running Oscillator

•48/60 MHz Free Running Oscillator (FRO).

•1 MHz Low-Power Internal Oscillator.

•Crystal oscillator.

•32 kHz Crystal Oscillator

•External Clock Input pin (50 MHz maximum)

10.13.1.1 12 MHz Free Running Oscillator (FRO)

The FRO 12 MHz oscillator provides the default clock at reset and provides a clean

system clock shortly after the supply pins reach operating voltage. This FRO oscillator,

factory trimmed for accuracy, that can optionally be used as a system clock as well as

other purposes

10.13.1.2 48/60 MHz Free Running Oscillator (FRO)

Selectable 48 MHz or 60 MHz FRO oscillator, factory trimmed for accuracy, that can

optionally be used as a system clock as well as other purposes.

Remark Semion 16.5

Product data sheet Rev. 1.7 — 20 January 2021 67 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.13.1.3 1 MHz Low-Power oscillator

The 1 MHz oscillator provides an ultra low-power, low-frequency clock source that can be

used to clock a variety of functions including the Watchdog Timer (WWDT) and the

OSTimer. It can also be used as the main system clock for low-power operation.

The 1 MHz Low Power oscillator is accurate to +/-10% over temperature.

10.13.1.4 Crystal oscillator

The main crystal oscillator on the RT600 can be used with crystal frequencies from 4 MHz

to 32 MHz. The crystal oscillator may be used to drive a PLL to achieve higher clock rates.

One aspect of the oscillator high gain mode is that a larger voltage swing is used at the

crystal pin. This gives a higher noise immunity within the oscillator and less edge to edge

jitter of the internal clock. When high gain mode is not required, power used by the crystal

oscillator can be reduced by using low power mode.

Remark: High gain mode requires a 1 megohm resistor to be inserted in parallel with the

crystal. See Section 16.5. For this reason, high gain mode and low power mode cannot

both be used in the same application. The board design must reflect the mode that will be

used.

10.13.1.5 32 kHz oscillator

The 32KHz oscillator resides in the “always-on” domain and is used to drive the Real Time

Clock. It is also available for use for a variety of other purposes including low-power UART

operation or as the main system clock for very low frequency operation.

10.13.2 System PLL (PLL0)

The system PLL accepts an input clock frequency in the range of 32.768 kHz to 25 MHz.

The input frequency is multiplied up to a high frequency with a Current Controlled

Oscillator (CCO).

The PLL can be enabled or disabled by software.

10.13.3 Audio PLL (PLL2)

The audio PLL accepts an input clock frequency in the range of 1 MHz to 25 MHz. The

input frequency is multiplied up to a high frequency with a Current Controlled Oscillator

(CCO).

The PLL can be enabled or disabled by software.

191212

Product data sheet Rev. 1.7 — 20 January 2021 68 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.13.4 Clock Generation

Fig 6. RT600 clock generation

191212

Primary clock sources (oscillators):

System clocking (PLLs, CPU clocks, etc.):

(1)

16m_irc

Main clock select B

MAINCLKSELB[1:0]

(1)

main_pll_clk

32k_clk

clk_in

Main clock select A

MAINCLKSELA[1:0]

48/60m_irc_div4

1m_lposc

48/60m_irc

main_clk

16 MHz

oscillator

16m_irc

PDRUNCFG0[15],

PDSLEEPCFG0[15]

xtalout

Enable & bypass

SYSOSCCTL0[1:0]

xtalin

Main crystal

oscillator

clk_in

clkin (selected by IOCON)

SYSOSCBYPASS[2:0]

rtcxout

Enable

OSC32KHZCTL0[0]

rtcxin

RTC crystal

oscillator

32k_clk

MCLK Clock Select

AUDIOMCLKSEL[2:0]

AUDIOMCLKDIV

MCLK

Divider

to MCLK pin

(output)audio_pll_clk

48/60m_irc

"none" 001

111

000

48/60 MHz

oscillator

Divide by 2

48/60m_irc

48/60m_irc_div2

48/60m_irc_div4

PDRUNCFG0[16],

PDSLEEPCFG0[16]

Audio PLL

Divider

clk_in

Audio PLL clock select

AUDIOPLL0CLKSEL[2:0]

16m_irc

48/60m_irc_div2 audio_pll_clk

Audio PLL settings

AUDIOPLL0xx

PFD0

PFD1

PFD2

PFD3

Audio

PLL

PFD0

111

001

010

000

"none"

AUDIOPLLCLKDIV

(1) : synchronized multiplexer,

see register descriptions

for details.

1m_lposc

divide by 32

WAKECLK32KHZSEL[2:0]

lp_32k

"none"

32k_clk

32k_wake_clk

to SDIO 32k, USB 32k,

ACMP sclk & rclk

1 MHz low

power osc. 001

111

000

PDRUNCFG0[14],

PDSLEEPCFG0[14]

clk_in

Sys PLL clock select

SYSPLL0CLKSEL[2:0]

16m_irc

48/60m_irc_div2 Main

PLL

PFD0

PFD1

PFD2

PFD3

Main PLL settings

SYSPLL0xx

111

001

010

000

"none"

MAINPLLCLKDIV

DSPPLLCLKDIV

AUX1PLLCLKDIV

Main PLL

Clock Divider

DSP PLL

Clock Divider

AUX1 PLL

Clock Divider

AUX0PLLCLKDIV

AUX0 PLL

Clock Divider

main_pll_clk

dsp_pll_clk

aux1_pll_clk

aux0_pll_clk

DSP clock select B

DSPCPUCLKSELB[1:0]

DSP clock select A

DSPCPUCLKSELA[1:0]

DSP Clock

Divider

main_pll_clk

(1)

dsp_pll_clk

32k_clk

clk_in

(1)

1m_lposc

16m_irc

48/60m_irc

DSPCPUCLKDIV

dsp_main_clk (to

CLKOUT 0 select)

to DSP CPU

DSP RAM

Clock Divider

DSPMAINRAMCLKDIV

to DSP RAM

interface

011

001

010

000

111

SYSCPUAHBCLKDIV

CPU Clock

Divider

to CPU, AHB, APB, etc.

hclk

SYSTICKFCLKSEL[2:0]

1m_lposc

32k_clk

16m_irc

ARM Trace

Clock Divider

to ARM Trace function clock

PFC0DIV

Systick Clock

Divider

SYSTICKFCLKDIV

to Systick

function clock

"none"

—————————+ + ‘ 4’ _. 4 1’ H ‘. _, + If , f 200221

Product data sheet Rev. 1.7 — 20 January 2021 69 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Fig 7. RT600 clock generation (continued)

HS SPI clock select

FC14FCLKSEL[2:0]

FRG14CTL[15:0]

frg_clk14

"none"

function clock

of HS SPI

48/60m_irc

16m_irc

audio_pll_clk

mclk_in 011

001

010

000

100

111

Fractional Rate

Divider (FRG)

HS SPI FRG clock select

FRG14CLKSEL[2:0]

frg_pll

main clk

"none" 011

001

010

000

111

48/60m_irc

16m_irc

USB clock select

USBHSFCLKSEL[2:0]

USBHSFCLKDIV

USB Clock

Divider

to HS

USB

clk_in

main_clk 001

111

000

"none"

I3C TC Select

I3C0FCLKSTCSEL[2:0]

I3C0FCLKSTCDIV

I3C TC

Divider

to I3C

clk_slow_tc

"none" 001

111

000

I3C Clock Select

I3C0FCLKSEL[2:0]

48/60m_irc

main_clk

"none" 001

111

000

I3C0FCLKDIV

I3C fclk

Divider

to I3C fclk

(should be a multiple

of 24 or 25 MHz)

I3C0FCLKSDIV

I3C TC

Divider

to I3C

clk_slow

1m_lposc

CLKCTL0_PFC1DIV

USB PHY bus

Clock Divider

to USB PHY

bus interface

main_clk

(max. 120 MHz)

HS SPI clock select

FC15FCLKSEL[2:0]

FRG15CTL[15:0]

frg_clk15

"none"

function clock

of PMIC I2C

48/60m_irc

16m_irc

audio_pll_clk

mclk_in 011

001

010

000

100

111

Fractional Rate

Divider (FRG)

PMIC I2C FRG clock select

FRG15CLKSEL[2:0]

frg_pll

main clk

"none" 011

001

010

000

111

48/60m_irc

16m_irc

FLEXSPIFCLKDIV

FlexSPI Clock

Divider

aux0_pll_clk

OSPI clock select

OSPIFFCLKSEL[2:0]

main_pll_clk

48/60m_irc

aux1_pll_clk

main clk

011

001

010

000

100

111

"none"

to FlexSPI

fclk

SDIO0 Clock

Divider

to SDIO0

fclk

aux0_pll_clk

SDIO 0 clock select

SDIO0FCLKSEL[2:0]

main_pll_clk

48/60m_irc

aux1_pll_clk

main clk

011

001

010

000

100

111

"none" SDIO0FCLKDIV

200221

SDIO1 Clock

Divider

to SDIO1

fclk

aux0_pll_clk

SDIO 1 clock select

SDIO1FCLKSEL[2:0]

main_pll_clk

48/60m_irc

aux1_pll_clk

main clk

011

001

010

000

100

111

"none" SDIO1FCLKDIV

Flexcomm n clock select

FCnFCLKSEL[2:0]

1 per Flexcomm interface (n = 0 through 7)

FRGnCTL[15:0]

frg_clk n

"none"

function clock

of Flexcomm n

48/60m_irc

16m_irc

audio_pll_clk

mclk_in 011

001

010

000

100

111

Fractional Rate

Divider (FRG)

FRG clock select n

FRGnCLKSEL[2:0]

frg_pll

main clk

"none" 011

001

010

000

111

48/60m_irc

16m_irc

PLL to Flexcomm

FRG Divider

main_pll_clk

FRGPLLCLKDIV

frg_pll

151220

Product data sheet Rev. 1.7 — 20 January 2021 70 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.13.5 Safety

The RT600 includes a Windowed WatchDog Timer (WWDT), which can be enabled by

software after reset. Once enabled, the WWDT remains locked and cannot be modified in

any way until a reset occurs.

Fig 8. RT600 clock generation (continued)

191220

Timer function clocks:

Other (analog, audio, misc.):

CLKOUT 1 select

CLKOUTSEL1[2:0]

CLKOUTDIV

CLKOUT

Divider

audio_pll_clk

32k_clk

main_pll_clk

aux0_pll_clk

dsp_pll_clk

aux1_pll_clk

"none"

011

001

010

000

100

101

110

111

CLKOUT

dsp_main_clk

clk_in

1m_lposc

48/60m_irc

16m_irc

main_clk

011

001

010

000

100

110

CLKOUT 0 select

CLKOUTSEL0[2:0]

ADC0FCLKDIV

ADC Clock

Divider

to ADC fclk

aux0_pll_clk

ADC clock select 1

ADC0FCLKSEL1[2:0]

main_pll_clk

aux1_pll_clk

101

001

011

000

111

"none"

ADC clock select 0

ADC0FCLKSEL0[2:0]

clk_in

1m_lposc

48/60m_irc

16m_irc

011

001

010

000

111

"none"

ACMP0FCLKDIV

ACMP Clock

Divider

to ACMP

fclk

48/60m_irc

ACMP clock select

ACMP0FCLKSEL[2:0]

16m_irc

aux0_pll_clk

aux1_pll_clk

main clk

011

001

010

000

100

111

"none"

DMIC0FCLKDIV

DMIC Clock

Divider

to D-Mic

subsystem

DMIC Clock Select

DMIC0FCLKSEL[2:0]

48/60m_irc

16m_irc

audio_pll_clk

1m_lposc

mclk_in

011

001

010

000

100

101

111

"none"

32k_wake_clk

111

001

010

000

OS Timer Clock Select

OSEVENTTFCLKSEL[2:0]

ostimer_clk

32k_clk

1m_lposc

hclk

"none"

TIMER n clock select

CT32BITnFCLKSEL[2:0]

16m_irc

48/60m_irc

audio_pll_clk

main clk

mclk_in

"none"

function clock of

CTIMER n

(CTIMERs 0 through 4)

011

001

010

000

100

111

SCTimer/PWM clock select

SCTFCLKSEL[2:0]

SCTFCLKDIV

SCTimer/PWM

Clock Divider

to SCTimer/PWM

input clock 7

main_pll_clk

aux0_pll_clk

48/60m_irc

main clk

aux1_pll_clk

audio_pll_clk

"none"

011

001

010

000

100

101

111

WDT0 Clock Select

WDT0FCLKSEL[2:0]

to WDT0

fclk

1m_lposc

"none"

111

000

WDT1 Clock Select

WDT1FCLKSEL[2:0]

to WDT1

fclk

1m_lposc

"none"

111

000

Utick Timer Clock Select

UTICKFCLKSEL[2:0]

to UTICK

fclk

1m_lposc

"none"

111

000

Product data sheet Rev. 1.7 — 20 January 2021 71 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.14 Power control

The RT600 supports a variety of power control features. In Active mode, when the chip is

running, power and clocks to selected peripherals can be adjusted for power

consumption. In addition, there are individual power-down controls for many (particularly

analog) peripherals. Finally, any set of individual shared Ram partitions may be placed in

retain/standby mode or powered-off entirely. This selection can be made on a

partition-by-partition basis.

In addition, there are three special modes of processor power reduction with different

peripherals running: sleep mode, deep-sleep mode, and deep power-down mode that can

be activated using the power API library from the SDK software package.

10.14.1 Sleep mode

There are independent sleep modes for each of the two CPUs. In sleep mode, the system

clock to that CPU is stopped and execution of instructions is suspended until either a reset

or an interrupt occurs. Peripheral functions, if selected to be clocked can continue

operation during Sleep mode and may generate interrupts to cause the processor to

resume execution. Sleep mode eliminates dynamic power used by the processor itself,

memory systems and related controllers, internal buses, and unused peripherals. The

processor state and registers, peripheral registers, and internal SRAM values are

maintained, and the logic levels of the pins remain static.

10.14.2 Deep-sleep mode

In deep-sleep mode, the system clock to the processor is disabled as in sleep mode. All

analog blocks are powered down by default but can be selected to keep running through

the power API if needed as wake-up sources. The main clock and all peripheral clocks are

disabled. The FRO is disabled.

Deep-sleep mode eliminates all power used by analog peripherals and all dynamic power

used by the processor itself, memory systems and related controllers, and internal buses.

The processor state and registers, peripheral registers, and internal SRAM values are

maintained, and the logic levels of the pins remain static.

GPIO Pin Interrupts, GPIO Group Interrupts, and selected peripherals such as USB0,

USB1, DMIC, SPI, I2C, USART, WWDT, RTC, Micro-tick Timer, and BOD can be left

running in deep sleep mode The FRO, RTC oscillator, and the watchdog oscillator can be

left running.In some cases, DMA can operate in deep-sleep mode. For more details, see

RT600 user manual.

10.14.3 Deep power-down mode and Full Deep power-down mode

In deep power-down mode, power is shut off to the entire chip except for the RTC power

domain, the RESET pin, and the PMIC_IRQ_N pin. The RT600 can wake up from deep

power-down mode via the RESET pin, the RTC alarm, and the PMIC_IRQ_N pin. The

ALARM1HZ flag in RTC control register generates an RTC wake-up interrupt request,

which can wake up the part. During deep power-down mode, the contents of the SRAM

and registers are not retained. All functional pins are tri-stated in deep power-down mode.

In deep power-down mode, all rails can remained powered and supply to the VDDCORE

supply can be powered down. In full deep power-down mode, all rails can be powered off

and the VDD_AO18 supply can remain powered.

Table 16

Product data sheet Rev. 1.7 — 20 January 2021 72 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.14.4 Peripheral configuration in reduced power modes

Tabl e 1 6 shows the peripheral configuration in reduced power modes.

[1] The comparator may be on in deep-sleep mode, but cannot generate a wake-up interrupt.

[2] Applies to both deep power-down and full deep power-down modes.

Table 16. Peripheral configuration in reduced power modes

Peripheral/Clock Reduced power mode

Sleep Deep-sleep Deep power-down[2]

1m_lposc Software configured Software configured Off

16m_irc Software configured Software configured Off

48/60m_irc Software configured Software configured Off

Crystal oscillator Software configured Software configured Off

RTC and RTC oscillator Software configured Software configured Software configured

System PLL Software configured Software configured Off

Audio PLL Software configured Software configured Off

SRAM memory arrays Software configured Software configured Off

SRAM periphery Software configured Software configured Off

Boot ROM On Off‘ Off

Other digital peripherals Software configured Software configured Off

A to D converter Software configured Software configured Off

Analog Comparator Software configured Software configured [1] Off

Table 17 activity. 7

Product data sheet Rev. 1.7 — 20 January 2021 73 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Tabl e 1 7 shows typical wake-up sources for reduced power modes.

[1] See specific peripheral chapter for basic configuration.

[2] The related interrupt must be enabled in the NVIC.

[3] Enable related function in the and STARTEN0 or STARTEN1 register.

[4] See Hardware Wake-up control register in UM

[5] Typically via the Message Unit interrupt. See Inter-CPU communications in UM chapter.

Table 17. Wake-up sources for reduced power modes

Power mode Wake-up source Comment

Sleep Any peripheral that can cause

an interrupt in sleep mode

[1][2]

HWWAKE Flexcomm Interfaces and DMIC subsystem activity. [4]

Deep-sleep Pin interrupts [1][2][3]

Watchdog interrupt Only WDT0 can generate a wake-up from deep-sleep mode. [1][2][3]

Watchdog reset Only WDT0 can generate a chip reset. [1]

Reset pin No configuration needed.

RTC 1 Hz alarm timer [1][2][3]

RTC_ALARM, RTC_WAKE [1][2][3]

Micro-tick timer Note: the Micro-tick timer is specifically targeted for ultra-low power wake-up

from deep-sleep mode [1][2][3]

OS Event Timer [1][2][3]

Flexcomm USART Interrupt from USART in slave or 32 kHz mode. [1][2][3]

Flexcomm SPI Interrupt from SPI in slave mode. [1][2][3]

Flexcomm I2C Interrupt from I2C in slave mode. [1][2][3]

Flexcomm I2S Interrupt from I2S in slave mode. [1][2][3]

I3C Interrupt from I3C in slave mode. [1][2][3]

USB need clock Interrupt from USB when activity is detected that requires a clock. [1][2][3][4]

DMA See DMA controller chapter in UM for details of DMA-related interrupts.

[1][2][3]

DMA controllers [1][2][3]

DMIC [1][2][3]

HWWAKE Certain Flexcomm Interface and DMIC subsystem activity. [4]

Quad/octal SPI [1][2][3]

SDIO [1][2][3]

HASH-AES [1][2][3]

CASPER [1][2][3]

PowerQuad [1][2][3]

A to D converter [1][2][3]

HiFi4 DSP [2][3][5]

Deep

power-down

RTC_ALARM, RTC_WAKE [1][2][3]

Reset pin No configuration needed.

Full deep

power-down

Same as deep power-down except that external power must be restored prior to wake-up.

Product data sheet Rev. 1.7 — 20 January 2021 74 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.15 General Purpose I/O (GPIO)

The RT600 provides GPIO ports with a total of up to 147 GPIO pins.

Device pins that are not connected to a specific peripheral function are controlled by the

GPIO registers. Pins may be dynamically configured as inputs or outputs. Separate

registers allow setting or clearing any number of outputs simultaneously. The current level

of a port pin can be read back no matter what peripheral is selected for that pin.

10.15.1 Features

•Accelerated GPIO functions:

–GPIO registers are located on the AHB so that the fastest possible I/O timing can

be achieved.

–Mask registers allow treating sets of port bits as a group, leaving other bits

unchanged.

–All GPIO registers are byte and half-word addressable.

–Entire port value can be written in one instruction.

•Bit-level set and clear registers allow a single instruction set or clear of any number of

bits in one port.

•Direction control of individual bits.

•All I/O default to inputs after reset.

•All GPIO pins can be selected to create an edge or level-sensitive GPIO interrupt

request.

•One GPIO group interrupt can be triggered by a combination of any pin or pins.

10.16 Pin interrupt/pattern engine

The pin interrupt block configures up to eight pins from all digital pins for providing eight

external interrupts connected to the NVIC. The pattern match engine can be used in

conjunction with software to create complex state machines based on pin inputs. Any

digital pin, independent of the function selected through the switch matrix can be

configured through the SYSCON block as an input to the pin interrupt or pattern match

engine. The registers that control the pin interrupt or pattern match engine are located on

the I/O+ bus for fast single-cycle access.

Product data sheet Rev. 1.7 — 20 January 2021 75 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.16.1 Features

•Pin interrupts:

–Up to eight pins can be selected from all GPIO pins on ports 0 and 1 as

edge-sensitive or level-sensitive interrupt requests. Each request creates a

separate interrupt in the NVIC.

–Edge-sensitive interrupt pins can interrupt on rising or falling edges or both.

–Level-sensitive interrupt pins can be HIGH-active or LOW-active.

–Pin interrupts can wake up the device from sleep mode and deep-sleep mode.

•Pattern match engine:

–Up to eight pins can be selected from all digital pins on ports 0 and 1 to contribute

to a boolean expression. The boolean expression consists of specified levels

and/or transitions on various combinations of these pins.

–Each bit slice minterm (product term) comprising of the specified boolean

expression can generate its own, dedicated interrupt request.

–Any occurrence of a pattern match can also be programmed to generate an RXEV

notification to the CPU. The RXEV signal can be connected to a pin.

–Pattern match can be used in conjunction with software to create complex state

machines based on pin inputs.

–Pattern match engine facilities wake-up only from active and sleep modes.

10.17 Communications peripherals

10.17.1 High-speed USB Host/Device interface (USB1)

The Universal Serial Bus (USB) is a 4-wire bus that supports communication between a

host and one or more (up to 127) peripherals. The host controller allocates the USB

bandwidth to attached devices through a token-based protocol. The bus supports hot

plugging and dynamic configuration of the devices. All transactions are initiated by the

host controller.

10.17.1.1 USB1 device controller

The device controller enables 480 Mbit/s data exchange with a USB host controller. It

consists of a register interface, serial interface engine, endpoint buffer memory. The serial

interface engine decodes the USB data stream and writes data to the appropriate

endpoint buffer. The status of a completed USB transfer or error condition is indicated via

status registers. An interrupt is also generated if enabled.

Features

•Fully compliant with USB 2.0 Specification (high speed).

•Supports 12 physical (6 logical) endpoints with up to 8 kB endpoint buffer RAM.

•Supports Control, Bulk, Interrupt and Isochronous endpoints.

•Scalable realization of endpoints at run time.

•Endpoint Maximum packet size selection (up to USB maximum specification) by

software at run time.

Product data sheet Rev. 1.7 — 20 January 2021 76 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•While USB is in the Suspend mode, the RT600 can enter one of the reduced power

modes and wake up on USB activity.

•Double buffer implementation for Bulk and Isochronous endpoints.

10.17.1.2 USB1 host controller

The host controller enables high speed data exchange with USB devices attached to the

bus. It consists of register interface and serial interface engine. The register interface

complies with the Enhanced Host Controller Interface (EHCI) specification.

Features

•EHCI compliant.

•Two downstream ports.

•Supports per-port power switching.

10.17.2 FlexSPI Flash Inerface

The Flexible Serial Peripheral Interface (FlexSPI) host controller supports up to two SPI

channels and up to 4 external devices. Each channel supports Single/Dual/Quad/Octal

mode data transfer (1/2/4/8 bidirectional data lines).

FlexSPI flash interface with 32 KB cache and dynamic decryption for execute-in-place and

supports DMA.

10.17.2.1 Features

•FlexSPI is compliant to JEDEC’s JESD151 v1.0 for xSPI standard specification

•Flexible sequence engine (LUT table) to support various vendor devices.

–Serial NOR Flash: XccelaFLash, HyperFlash, EcoXiP Flash, Octa Flash, and all

QSPI flash devices

–Serial NAND Flash

–Serial pSRAM: HyperRAM, Xccela RAM (IoTRAM)

–FPGA device

•Flash access mode

–Single/Dual/Quad/Octal mode

–SDR/DDR mode

–Individual/Parallel mode

•Support sampling clock mode:

–Internal dummy read strobe looped back internally

–Internal dummy read strobe looped back from pad

–Flash provided read strobe

•Automatic Data Learning to select correct sample clock phase

•Memory mapped read/write access by AHB Bus

–AHB RX Buffer implemented to reduce read latency. Total AHB RX Buffer size: 256

* 64 Bits

–16 AHB masters supported with priority for read access

Product data sheet Rev. 1.7 — 20 January 2021 77 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

–8 flexible and configurable buffers in AHB RX Buffer

–AHB TX Buffer implemented to buffer all write data from one AHB burst. AHB TX

Buffer size: 8 * 64 Bits

–All AHB masters share this AHB TX Buffer. No AHB master number limitation for

Write Access.

•Software triggered Flash read/write access by IP Bus

–IP RX FIFO implemented to buffer all read data from External device. FIFO size:

64 * 64 Bits

–IP TX FIFO implemented to buffer all Write data to External device. FIFO size: 128

* 64 Bits

–DMA support to fill IP TX FIFO

–DMA support to read IP RX FIFO

–SCLK stopped when reading flash data and IP RX FIFO is full

–SCLK stopped when writing flash data and IP TX FIFO is empty

10.17.3 SD/eMMC Interfaces

SD/eMMC memory card interface is available with dedicated DMA controller. Supports the

eMMC 5.0 standard including HS400 DDR mode. HS-400 is supported on SD port 0 only.

10.17.4 Flexcomm Interface serial communication

10.17.4.1 Features

•USART with asynchronous operation or synchronous master or slave operation.

•SPI master or slave, with up to 4 slave selects.

•I2C, including separate master, slave, and monitor functions.

•Two I2S functions using Flexcomm Interface 6 and Flexcomm Interface 7.

•Data for USART, SPI, and I2S traffic uses the Flexcomm Interface FIFO. The I2C

function does not use the FIFO.

10.17.4.2 SPI serial I/O controller (Flexcomm Interfaces 0 - 7)

Features

•Excluding delays introduced by external device and PCB, The maximum supported bit

rate for SPI master mode (transmit/receive) is 25 Mbit/s and the maximum supported

bit rate for SPI slave mode (transmit/receive) is 25 Mbit/s.

•Data frames of 1 to 16 bits supported directly. Larger frames supported by software or

DMA set-up.

•Master and slave operation.

•Data can be transmitted to a slave without the need to read incoming data. This can

be useful while setting up an SPI memory.

•Control information can optionally be written along with data. This allows very

versatile operation, including “any length” frames.

•Four Slave Select input/outputs with selectable polarity and flexible usage.

Product data sheet Rev. 1.7 — 20 January 2021 78 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•Activity on the SPI in slave mode allows wake-up from deep-sleep mode on any

enabled interrupt.

Remark: Texas Instruments SSI and National Microwire modes are not supported.

10.17.4.3 I2C-bus interface

The I2C-bus is bidirectional for inter-IC control using only two wires: a serial clock line

(SCL) and a serial data line (SDA). Each device is recognized by a unique address and

can operate as either a receiver-only device (for example, an LCD driver) or a transmitter

with the capability to both receive and send information (such as memory). Transmitters

and/or receivers can operate in either master or slave mode, depending on whether the

chip has to initiate a data transfer or is only addressed. The I2C is a multi-master bus and

can be controlled by more than one bus master connected to it.

Features

•All I2Cs support standard, Fast-mode, and Fast-mode Plus with data rates of up to

1Mbit/s.

•All I2Cs support high-speed slave mode with data rates of up to 3.4 Mbit/s.

•Independent Master, Slave, and Monitor functions.

•Supports both Multi-master and Multi-master with Slave functions.

•Multiple I2C slave addresses supported in hardware.

•One slave address can be selectively qualified with a bit mask or an address range in

order to respond to multiple I2C-bus addresses.

•10-bit addressing supported with software assist.

•Supports SMBus.

•Activity on the I2C in slave mode allows wake-up from deep-sleep mode on any

enabled interrupt.

10.17.4.4 USART

Features

•Excluding delays introduced by external device and PCB, the maximum bit rates of

6.25 Mbit/s in asynchronous mode.

•Excluding delays introduced by external device and PCB, the maximum supported bit

rate for USART master synchronous mode is 20 Mbit/s, and the maximum supported

bit rate for USART slave synchronous mode is 20.0 Mbit/s.

•7, 8, or 9 data bits and 1 or 2 stop bits.

•Synchronous mode with master or slave operation. Includes data phase selection and

continuous clock option.

•Multiprocessor/multidrop (9-bit) mode with software address compare.

•RS-485 transceiver output enable.

•Autobaud mode for automatic baud rate detection

•Parity generation and checking: odd, even, or none.

•Software selectable oversampling from 5 to 16 clocks in asynchronous mode.

•One transmit and one receive data buffer.

Product data sheet Rev. 1.7 — 20 January 2021 79 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•RTS/CTS for hardware signaling for automatic flow control. Software flow control can

be performed using Delta CTS detect, Transmit Disable control, and any GPIO as an

RTS output.

•Received data and status can optionally be read from a single register

•Break generation and detection.

•Receive data is 2 of 3 sample "voting". Status flag set when one sample differs.

•Built-in Baud Rate Generator with auto-baud function.

•A fractional rate divider is shared among all USARTs.

•Interrupts available for Receiver Ready, Transmitter Ready, Receiver Idle, change in

receiver break detect, Framing error, Parity error, Overrun, Underrun, Delta CTS

detect, and receiver sample noise detected.

•Loopback mode for testing of data and flow control.

•In synchronous slave mode, wakes up the part from deep-sleep mode.

•Special operating mode allows operation at up to 9600 baud using the 32.768 kHz

RTC oscillator as the UART clock. This mode can be used while the device is in

deep-sleep mode and can wake-up the device when a character is received.

• USART transmit and receive functions work with the system DMA controller.

10.17.4.5 I2S-bus interface

The I2S bus provides a standard communication interface for streaming data transfer

applications such as digital audio or data collection. The I2S bus specification defines a

3-wire serial bus, having one data, one clock, and one word select/frame trigger signal,

providing single or dual (mono or stereo) audio data transfer as well as other

configurations. In the RT600, the I2S function is included in Flexcomm Interface 6 and

Flexcomm Interface 7. Each of the Flexcomm Interface implements four I2S channel pairs.

The I2S interface within one Flexcomm Interface provides at least one channel pair that

can be configured as a master or a slave. Other channel pairs, if present, always operate

as slaves. All of the channel pairs within one Flexcomm Interface share one set of I2S

signals, and are configured together for either transmit or receive operation, using the

same mode, same data configuration and frame configuration. All such channel pairs can

participate in a time division multiplexing (TDM) arrangement. For cases requiring an

MCLK input and/or output, this is handled outside of the I2S block in the system level

clocking scheme.

Features

•A Flexcomm Interface may implement one or more I2S channel pairs, the first of which

could be a master or a slave, and the rest of which would be slaves. All channel pairs

are configured together for either transmit or receive and other shared attributes. The

number of channel pairs is defined for each Flexcomm Interface, and may be from 0

to 4.

•Configurable data size for all channels within one Flexcomm Interface, from 4 bits to

32 bits. Each channel pair can also be configured independently to act as a single

channel (mono as opposed to stereo operation).

•All channel pairs within one Flexcomm Interface share a single bit clock (SCK) and

word select/frame trigger (WS), and data line (SDA).

Product data sheet Rev. 1.7 — 20 January 2021 80 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•Data for all I2S traffic within one Flexcomm Interface uses the Flexcomm Interface

FIFO. The FIFO depth is 8 entries.

•Left justified and right justified data modes.

•DMA support using FIFO level triggering.

•TDM (Time Division Multiplexing) with a several stereo slots and/or mono slots is

supported. Each channel pair can act as any data slot. Multiple channel pairs can

participate as different slots on one TDM data line.

•The bit clock and WS can be selectively inverted.

•Sampling frequencies supported depends on the specific device configuration and

applications constraints (for example, system clock frequency and PLL availability.)

but generally supports standard audio data rates. See the data rates section in I2S

chapter in the RT6xx user manual to calculate clock and sample rates.

10.17.5 High-Speed SPI interface (Flexcomm Interface 14)

An additional, stand-alone SPI module is provided. This will be a high-speed SPI able to

provide 50 MHz transfer rates. Functionally, it is identical to the SPI Flexcomm interfaces

0 to 7. Excluding delays introduced by external device and PCB, the maximum supported

bit rate for SPI master mode (transmit/receive) is 50 Mbit/s. The maximum supported bit

rate for SPI slave mode (receive) is 50Mbit/s and for SPI slave mode (transmit) is 35

Mbit/s.

10.17.6 I3C interface

The MIPI Alliance Improved Inter-Integrated Circuit (MIPI I3C) brings major improvements

in use and power over I2C, and provides an alternative to SPI for mid-speed

applications.The I3C bus is designed to support future sensor interface architectures,

widely expected in Internet-of-Things applications.

The I3C bus is intended to be used by microcontrollers (MCU) and application processors

(AP) to connect to sensors, actuators, and other MCUs (as slaves). Connecting an MCU

to other MCUs and connecting an AP to an MCU are considered to be the major use

cases.

10.17.6.1 Features

•In-band interrupts: interrupts can go from Slave to Master without extra wires, such

that the Master knows which Slave sent the interrupt.

•In-band command codes (Common Command Codes (CCC))

•Dynamic addressing

•Multi-master / multi-drop

•Hot-Join

•I2C compatibility. Note that I2C compatibility has limitations. Please refer to user

manual for further details.

10.18 Counter/timer peripherals

10.18.1 General-purpose 32-bit timers/external event counter

The RT600 includes five general-purpose 32-bit timer/counters.

Product data sheet Rev. 1.7 — 20 January 2021 81 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

The timer/counter is designed to count cycles of the system derived clock or an

externally-supplied clock. It can optionally generate interrupts, generate timed DMA

requests, or perform other actions at specified timer values, based on four match

registers. Each timer/counter also includes two capture inputs to trap the timer value when

an input signal transitions, optionally generating an interrupt.

10.18.1.1 Features

•A 32-bit timer/counter with a programmable 32-bit prescaler.

•Counter or timer operation.

•Up to four 32-bit captures can take a snapshot of the timer value when an input signal

transitions. A capture event may also optionally generate an interrupt. The number of

capture inputs for each timer that are actually available on device pins may vary by

device.

•Four 32-bit match registers that allow:

–Continuous operation with optional interrupt generation on match.

–Stop timer on match with optional interrupt generation.

–Reset timer on match with optional interrupt generation.

–Shadow registers are added for glitch-free PWM output.

•For each timer, up to four external outputs corresponding to match registers with the

following capabilities (the number of match outputs for each timer that are actually

available on device pins may vary by device):

–Set LOW on match.

–Set HIGH on match.

–Toggle on match.

–Do nothing on match.

•Up to two match registers can be used to generate timed DMA requests.

•The timer and prescaler may be configured to be cleared on a designated capture

event. This feature permits easy pulse width measurement by clearing the timer on

the leading edge of an input pulse and capturing the timer value on the trailing edge.

•Up to four match registers can be configured for PWM operation, allowing up to three

single edged controlled PWM outputs. (The number of match outputs for each timer

that are actually available on device pins may vary by device.)

10.18.2 SCTimer/PWM

The SCTimer/PWM allows a wide variety of timing, counting, output modulation, and input

capture operations. The inputs and outputs of the SCTimer/PWM are shared with the

capture and match inputs/outputs of the 32-bit general-purpose counter/timers.

The SCTimer/PWM can be configured as two 16-bit counters or a unified 32-bit counter. In

the two-counter case, in addition to the counter value the following operational elements

are independent for each half:

•State variable.

•Limit, halt, stop, and start conditions.

•Values of Match/Capture registers, plus reload or capture control values.

Product data sheet Rev. 1.7 — 20 January 2021 82 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

In the two-counter case, the following operational elements are global to the

SCTimer/PWM, but the last three can use match conditions from either counter:

•Clock selection

•Inputs

•Events

•Outputs

•Interrupts

10.18.2.1 Features

•Two 16-bit counters or one 32-bit counter.

•Counter(s) clocked by bus clock or selected input.

•Up counter(s) or up-down counter(s).

•State variable allows sequencing across multiple counter cycles.

•Event combines input or output condition and/or counter match in a specified state.

•Events control outputs, interrupts, and the SCTimer/PWM states.

–Match register 0 can be used as an automatic limit.

–In bi-directional mode, events can be enabled based on the count direction.

–Match events can be held until another qualifying event occurs.

•Selected event(s) can limit, halt, start, or stop a counter.

•Supports:

–8 inputs

–10 outputs

–16 match/capture registers

–16 events

–32 states

•PWM capabilities including dead time and emergency abort functions

10.18.3 Windowed WatchDog Timer (WWDT)

The purpose of the watchdog is to reset the controller if software fails to periodically

service it within a programmable time window.

A separate Watchdog Timer is provided for each of the two CPUs.

10.18.3.1 Features

•Internally resets chip if not periodically reloaded during the programmable time-out

period.

•Optional windowed operation requires reload to occur between a minimum and

maximum time period, both programmable.

•Optional warning interrupt can be generated at a programmable time prior to

watchdog time-out.

•Enabled by software but requires a hardware reset or a watchdog reset/interrupt to be

disabled.

Product data sheet Rev. 1.7 — 20 January 2021 83 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•Incorrect feed sequence causes reset or interrupt if enabled.

•Flag to indicate watchdog reset.

•Programmable 24-bit timer with internal prescaler.

•Selectable time period from (Tcy(WDCLK) 256 4) to (Tcy(WDCLK) 224 4) in

multiples of Tcy(WDCLK) 4.

•The Watchdog Clock (WDCLK) uses the WDOSC as the clock source.

10.18.4 Real Time Clock (RTC) timer

The RTC timer is a 32-bit timer which counts down from a preset value to zero. At zero,

the preset value is reloaded and the counter continues. The RTC timer uses the 32.768

kHz clock input to create a 1 Hz or 1 kHz clock. Selectable on-chip crystal load capacitors

are available for the RTC Oscillator.

10.18.5 Multi-Rate Timer (MRT)

The Multi-Rate Timer (MRT) provides a repetitive interrupt timer with four channels. Each

channel can be programmed with an independent time interval, and each channel

operates independently from the other channels.

10.18.5.1 Features

•24-bit interrupt timer.

•Four channels independently counting down from individually set values.

•Repeat and one-shot interrupt modes.

10.18.6 OS/Event Timer

An OS/EVENT Timer module will provide a common time-base between the two CPUs for

event synchronization and time-stamping.

The OS/EVENT Timer is comprised of a shared, free-running counter readable by each

CPU and individual match and capture registers for each CPU.

The shared and local counters in this module will be implemented using Gray code. This

will enable them to be read asynchronously by the processing domains.

The main counter in the OS/EVENT Timer module begins counting immediately following

power-up and continues counting through any subsequent system resets (except those

caused by a new POR).

10.18.6.1 Features

•64-bit Gray code counter. Using Gray code means that the timer can run at a a

frequency unrelated to either CPU clock and can still be read by either CPU without a

synchronization delay. Gray code is a reflected binary code that changes in a single

bit position for each increment.

•Separate functions for each CPU:

•A capture register can copy the main counter value when triggered by a CPU

request.

•A match register can be compared to the main counter and can optionally generate an

interrupt or wake-up event

Product data sheet Rev. 1.7 — 20 January 2021 84 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.18.7 Micro-Tick Timer

A 32-bit MicroTick timer that runs from the 1 MHz low-power oscillator. This timer can

wake up the device from reduced power modes up to deep-sleep, with extremely low

power consumption. The MicroTick timer has an added timestamp feature in the form of 4

capture registers.

10.18.7.1 Features

•Ultra simple, ultra-low power timer that can run and wake up the device in reduced

power modes other than deep power-down.

•Write once to start.

•Interrupt or software polling.

•Four capture registers that can be triggered by external pin transitions.

10.19 Other digital peripherals

10.19.1 DMA controller

The DMA controller allows peripheral-to memory, memory-to-peripheral, and

memory-to-memory transactions. Each DMA stream provides unidirectional DMA

transfers for a single source and destination.

Two identical DMA controllers are provided on the RT600. The user may elect to dedicate

one of these to the Cortex M-33 CPU and the other for use by the DSP CPU and/or one

may be used as a secure DMA the other non-secure.

10.19.1.1 Features

•One channel per on-chip peripheral direction: typically one for input and one for output

for most peripherals.

•DMA operations can optionally be triggered by on- or off-chip events.

•Priority is user selectable for each channel.

•Continuous priority arbitration.

•Address cache.

•Efficient use of data bus.

•Supports single transfers up to 1,024 words.

•Address increment options allow packing and/or unpacking data.

10.19.2 DMIC subsystem

10.19.2.1 Features

•Pulse-Density Modulation (PDM) data input for left and/or right channels on 1 or 2

buses.

•Flexible decimation.

•16 entry FIFO for each channel.

•DC blocking or unaltered DC bias can be selected.

Product data sheet Rev. 1.7 — 20 January 2021 85 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•Data can be transferred using DMA from deep-sleep mode without waking up the

CPU, then automatically returning to deep-sleep mode.

•Data can be streamed directly to I2S on Flexcomm Interface 7.

10.19.3 CRC engine

The Cyclic Redundancy Check (CRC) generator with programmable polynomial settings

supports several CRC standards commonly used. To save system power and bus

bandwidth, the CRC engine supports DMA transfers.

10.19.3.1 Features

•Supports three common polynomials CRC-CCITT, CRC-16, and CRC-32.

–CRC-CCITT: x16 + x12 + x5 + 1

–CRC-16: x16 + x15 + x2 + 1

–CRC-32: x32 + x26 + x23 + x22 + x16 + x12 + x11 + x10 + x8 + x7 + x5 + x4 + x2 + x + 1

•Bit order reverse and 1’s complement programmable setting for input data and CRC

sum.

•Programmable seed number setting.

•Supports CPU PIO or DMA back-to-back transfer.

•Accept any size of data width per write: 8, 16 or 32-bit.

–8-bit write: 1-cycle operation.

–16-bit write: 2-cycle operation (8-bit x 2-cycle).

–32-bit write: 4-cycle operation (8-bit x 4-cycle).

10.20 Analog peripherals

10.20.1 12-bit Analog-to-Digital Converter (ADC)

The ADC supports a resolution of 12-bit and fast conversion rates of up to 5 Msamples/s.

Sequences of analog-to-digital conversions can be triggered by multiple sources. Possible

trigger sources are the SCTimer/PWM, external pins, and the Arm TXEV interrupt.

The ADC supports a variable clocking scheme with clocking synchronous to the system

clock or independent, asynchronous clocking for high-speed conversions

The ADC includes a hardware threshold compare function with zero-crossing detection.

The threshold crossing interrupt is connected internally to the SCTimer/PWM inputs for

tight timing control between the ADC and the SCTimer/PWM.

10.20.1.1 Features

•12-bit successive approximation analog to digital converter.

•Input multiplexing among up to 12 pins.

•Two configurable conversion sequences with independent triggers.

•Optional automatic high/low threshold comparison and “zero crossing” detection.

•Measurement range VREFN to VREFP (typically 3 V; not to exceed VDDA voltage

level).

Product data sheet Rev. 1.7 — 20 January 2021 86 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

•12-bit conversion rate of 5.0 Msamples/s. Options for reduced resolution at higher

conversion rates.

•Burst conversion mode for single or multiple inputs.

•Synchronous or asynchronous operation. Asynchronous operation maximizes

flexibility in choosing the ADC clock frequency, Synchronous mode minimizes trigger

latency and can eliminate uncertainty and jitter in response to a trigger.

10.20.2 Temperature sensor

The temperature sensor transducer uses an intrinsic pn-junction diode reference and

outputs a CTAT voltage (Complement To Absolute Temperature). The temperature sensor

is only approximately linear with a slight curvature. The output voltage is measured over

different ranges of temperatures and fit with linear-least-square lines.

After power-up, the temperature sensor output must be allowed to settle to its stable value

before it can be used as an accurate ADC input.

10.20.3 Analog Comparator

The comparator (CMP) module provides a circuit for comparing two analog input voltages.

The comparator circuit is designed to operate across the full range of the supply voltage,

known as rail-to-rail operation.

10.21 Security features

The security system on RT600 has a set of hardware blocks and ROM code to implement

the security features of the device. The hardware consists of an AES engine, a SHA

engine (Hash-AES block), a random number generator, and a key storage block that keys

from an SRAM based PUF (Physically Unclonable Function). All components of the

system can be accessed by the processor or the DMA engine to encrypt or decrypt data

and for hashing. The ROM is responsible for secure boot in addition to providing support

for various security functions.

10.21.1 Features

•Trust Zone M

•AES256 Decryption Engine.

•SHA-1, SHA-2 HASH Engine.

•Physical Unclonable Function (PUF) Key Generation.

•CASPER security Cortex-M33 co-processor.

•Random number generator (RNG).

•On-the-Fly Decryption on Octal/Quad0 SPI interface.

•Universally Unique Identifier (UUID)

•Device Identifier Composition Engine (DICE)

10.21.2 AES256

RT600 devices provide an on-chip hardware AES encryption and decryption engine to

protect the image content and to accelerate processing for data encryption or decryption,

data integrity, and proof of origin. Data can be encrypted or decrypted by the AES engine

using a key from the PUF or a software supplied key.

Product data sheet Rev. 1.7 — 20 January 2021 87 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.21.3 SHA-1 and SHA-2

The Hash peripheral is used to perform SHA-1 and SHA-2 (256) based hashing. A hash

takes an arbitrarily large message or image and forms a relatively small fixed size

“unique” number called a digest. The data is fed by words from the processor, DMA, or

hosted access; the words are converted from little-endian (Arm standard) to big-endian

(SHA standard) by the block.

10.21.3.1 Features

•Used with an HMAC to support a challenge/response or to validate a message.

•Can be used to verify external memory that has not been compromised.

10.21.4 PUF

The PUF controller provides a secure key storage without injecting or provisioning device

unique PUF root key.

10.21.4.1 Features

•Key strength of 256 bits. The PUF constructs 256-bit strength device unique PUF root

key using the digita fingerprint of a device derived from SRAM and error correction

data called Activation Code (AC). The AC is generated during enrollment process and

must be stored on external non-volatile memory device in the system.

•Generation, storage, and reconstruction of keys.

•Key sizes from 64 bits to 4096 bits.PUF controller allows storage of keys, generated

externally or on chip, of sizes 64 bits to 4096 bits

•PUF controller allows to assign a 4-bit index value for each key while generating key

codes. Keys that are assigned index value zero are output through HW bus,

accessible to AES engine and OTFAD block only. Keys with non-zero index are

available through APB register interface

10.21.5 CASPER co-processor

The Cryptographic Accelerator (CASPER) engine provides acceleration of asymmetric

cryptographic algorithms. When the Cryptographic Accelerator (CASPER) is used in

conjunction with hardware blocks for hashing and symmetric cryptography, significant

performance can be achieved. Supported crypto functions are implemented in the SDK

(Software Development Kit) and the mbed TLS examples utilize the CASPER peripheral

for computations.

10.21.6 Random Number Generator (RNG)

Random Number Generators (RNG) are used for cryptographic, modeling, and simulation

applications, which employ keys that must be generated in a random fashion.

10.21.7 On-the-Fly Decryption on Octal/Quad SPI interface (OTFAD)

The OTFAD function provides AES-128 Counter Mode On-the-Fly Decryption of external

data located on the Quad/octal SPI flash interface (QuadSPI) interface.

Product data sheet Rev. 1.7 — 20 January 2021 88 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

10.21.8 Universally Unique Identifier (UUID)

The RT600 stores a 128-bit IETF RFC4122 compliant non-sequential Universally Unique

Identifier (UUID). It can be read from registers SYSCTL0_UUID0 through

SYSCTL0_UUID3

10.21.9 Device Identifier Composition Engine (DICE)

The RT600 supports Device Identifier Composition Engine (DICE) to provide Composite

Device Identifier (CDI). CDI value would be available in registers

SYSCTL0DICEHWREG0 through SYSCTL0DICEHWREG7 for consumption after boot

completion. It is recommended to overwrite these registers once ephemeral key-pairs are

generated using this value.

10.22 Emulation and debugging

Debug and trace functions are integrated into the Arm Cortex-M33. Serial wire debug and

trace functions are supported. The Arm Cortex-M33 is configured to support up to eight

breakpoints and four watch points.

The Arm SYSREQ reset is supported and causes the processor to reset the peripherals,

execute the boot code, restart from address 0x0000 0000, and break at the user entry

point.

The SWD pins are multiplexed with other digital I/O pins. On reset, the pins assume the

SWD functions by default.

Product data sheet Rev. 1.7 — 20 January 2021 89 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

11. Limiting values

Table 18. Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).[1]

Symbol Parameter Conditions Min Max Unit

VDD_AO1V8 Supply 1.8 V supply for

“always on” features.

[2] -0.3 1.98 V

VDD1V8 1.8 V supply voltage for

on-chip analog functions

other than the ADC and

comparator.

[2] -0.3 1.98 V

VDD1V8_1 1.8 V supply voltage for OTP. [2] -0.3 1.98 V

VDDCORE Power supply for core logic On-chip regulator not used.

Power supplied by an off-chip

power management IC (PMIC).

[2] -0.3 1.155 V

VDDIO_0/1/2 Supply voltage for GPIO pins [2] -0.3 3.96 V

VDDA_ADC1V8 1.8 V analog supply voltage

for ADC and comparator.

[2] -0.3 1.98 V

VDDA_BIAS Bias for ADC and

comparator. VDD_BIAS must

equal to the highest VDDIO

rail voltage used for the ADC

input channel or comparator

inputs.

[2] -0.3 3.96 V

VREFP ADC positive reference

voltage

[2] -0.3 1.98 V

USB1_VDD3V3 USB1 analog 3.3 V supply [2] -0.3 3.96 V

IDD supply current (VFBGA176) per VDDIO pin,

1.71 V  VDDIO  3.6 V

[3] - 100 mA

supply current (WLCSP114) per VDDIO pin,

1.71 V  VDDIO  3.6 V

[3] - 100 mA

supply current (FOWLP249) per VDDIO pin,

1.71 V  VDDIO  3.6 V

[3] - 100 mA

ISS ground current (VFBGA176) 1.71 V  VDDIO  3.6 V [3] - 100 mA

ground current (WLCSP114) 1.71 V  VDDIO  3.6 V [3] - 100 mA

ground current (FOWLP249) 1.71 V  VDDIO  3.6 V [3] - 100 mA

Ilatch I/O latch-up current (0.5VDD) < VI < (1.5VDD);

Tj < 125 C

- 100 mA

Tstg storage temperature -55 150 C

Tj(max) maximum junction

temperature

- 105 C

Ptot(pack) total power dissipation (per

package)

VFBGA176, based on package

heat transfer, not device power

consumption

[5] -1W

Product data sheet Rev. 1.7 — 20 January 2021 90 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[1] The following applies to the limiting values:

a) This product includes circuitry specifically designed for the protection of its internal devices from the damaging effects of excessive

static charge. Nonetheless, it is suggested that conventional precautions be taken to avoid applying greater than the rated

maximum.

b) Parameters are valid over operating temperature range unless otherwise specified. All voltages are with respect to VSS unless

otherwise noted.

c) The limiting values are stress ratings only and operating the part at these values is not recommended and proper operation is not

guaranteed. The conditions for functional operation are specified in Table 30.

[2] Maximum/minimum voltage above the maximum operating voltage (see Ta b l e 3 0 ) and below ground that can be applied for a short time

(< 10 ms) to a device without leading to irrecoverable failure. Failure includes the loss of reliability and shorter lifetime of the device.

[3] The peak current should not exceed the total supply current.

[4] Human body model: equivalent to discharging a 100 pF capacitor through a 1.5 k series resistor.

[5] Determined in accordance to JEDEC JESD51-2A natural convection environment (still air).

Ptot(pack) total power dissipation (per

package)

WLSCP114, based on package

heat transfer, not device power

consumption

[5] -1W

Ptot(pack) total power dissipation (per

package)

FOWLP249, based on package

heat transfer, not device power

consumption

[5] -1.1W

VESD electrostatic discharge

voltage

human body model; all pins [4] - 2000 V

Table 18. Limiting values …continued

In accordance with the Absolute Maximum Rating System (IEC 60134).[1]

Symbol Parameter Conditions Min Max Unit

T T +(P x1e )

Product data sheet Rev. 1.7 — 20 January 2021 91 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

12. Thermal characteristics

The average chip junction temperature, Tj (C), can be calculated using the following

equation:

(1)

•Tamb = ambient temperature (C),

•Rth(j-a) = the package junction-to-ambient thermal resistance (C/W)

•PD = sum of internal and I/O power dissipation

The internal power dissipation is the product of IDD and VDD. The I/O power dissipation of

the I/O pins is often small and many times can be negligible. However it can be significant

in some applications. Determined in accordance to JEDEC JESD51-2A natural

convection environment (still air). Thermal resistance data in this report is solely for a

thermal performance comparison of one package to another in a standardized specified

environment. It is not meant to predict the performance of a package in an

application-specific environment.

[1] Determined in accordance to JEDEC JESD51-2A natural convection environment (still air). Thermal

resistance data in this report is solely for a thermal performance comparison of one package to another in a

standardized specified environment. It is not meant to predict the performance of a package in an

application-specific environment.

Table 19. Thermal resistance [1]

Symbol Parameter Conditions Max/Min Unit

VFBGA176 Package

Rth(j-a) thermal resistance from

junction to ambient

JESD51-9, 2s2p, still air 32.8 C/W

WLCSP114 Package

Rth(j-a) thermal resistance from

junction to ambient

JESD51-9, 2s2p, still air 35.3 C/W

FOWLP249 Package

Rth(j-a) thermal resistance from

junction to ambient

JESD51-9, 2s2p, still air 29.6 C/W

TjTamb PDRth j a–

+=

VDD1VB_1 7

Product data sheet Rev. 1.7 — 20 January 2021 92 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

13. Static characteristics

13.1 General operating conditions

Table 20. General operating conditions

Tamb =0



C to +85



C, unless otherwise specified.

Symbol Parameter Conditions Min Typ[1] Max Unit

fclk CPU (Cortex-M33) clock frequency. - - 300 MHz

CPU (Cortex-M33) clock frequency. For USB high-speed device and

host operations.

90 - 300 MHz

CPU (Cortex-M33) clock frequency. For USB full-speed device and

host operations.

12 - 300 MHz

fclk DSP clock frequency - - 600 MHz

VDD_AO1V8 Supply 1.8 V supply for “always on”

features.

1.71 -1.89V

VDD1V8 1.8 V supply voltage for on-chip analog

functions other than the ADC and

comparator.

1.71 -1.89V

VDD1V8_1 [4] 1.8 V supply voltage for OTP. 1.71 -1.89V

VDDCORE

[3][5][6][7]

Power supply for core logic. On-chip

regulator not used. Power supplied by

an off-chip power management IC

(PMIC).

Retention Mode 0.7 - 1.155 V

Low voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(M33 Max Freq = 70 MHz, FBB).

0.7 - 1.155 V

Active Mode

(M33 Max Freq = 150 MHz, FBB).

0.8 - 1.155 V

Active Mode

(M33 Max Freq = 220 MHz, FBB).

0.9 - 1.155 V

Full voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(M33 Max Freq = 65 MHz, FBB).

0.7 - 1.155 V

Active Mode

(M33 Max Freq = 140 MHz, FBB).

0.8 - 1.155 V

Active Mode

(M33 Max Freq = 210 MHz, FBB).

0.9 - 1.155 V

Active Mode

(M33 Max Freq = 275 MHz, FBB).

1.0 - 1.155 V

Active Mode

(M33 Max Freq = 300 MHz, FBB).

1.13 - 1.155 V

VDDA_B|AS 7

Product data sheet Rev. 1.7 — 20 January 2021 93 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

[1] Typical ratings are not guaranteed. The values listed are for room temperature (25 C), nominal supply voltages.

[2] VDD_BIAS must be connected to the highest VDDIO rail voltage used for the ADC input channel or comparator inputs.

[3] For SDK version 2.8.3 and after (SDK Power Library version = 0x02030): The maximum frequency for the specified VDDCORE voltage

is the frequency of the clock after CPU CLOCK and DSP clock Divider. The VDDCORE voltage has to be set according to the chosen

M33 CPU and DSP CPU clock frequency. Please see Figure 6 “RT600 clock generation”.

[4] 1.8 V supply voltage for OTP during active mode. In deep-sleep mode, this pin can be powered off to conserve additional current (~ 65

uA). VDD1V8_1 must be stable before performing any OTP related functions.

[5] When LDO_ENABLE is externally tied low, the user must boot at VDDCORE = 1.0 V or higher (Low power/Normal clock mode - OTP

setting - BOOT_CLK_SPEED) or VDDCORE = 1.13 V (High Speed clock - OTP setting - BOOT_CLK_SPEED). Thereafter, the

VDDCORE can be adjusted to the desired level.

[6] When LDO_ENABLE is externally tied high, the on-chip regulator to the VDDCORE Core voltage in PMC is set to the default value 1.05

V (Low power/Normal clock mode - OTP setting - BOOT_CLK_SPEED) or 1.13 V (High Speed clock - OTP setting -

BOOT_CLK_SPEED). Thereafter, the POWER_SetLdoVoltageForFreq API function can be used to internally configure the on-chip

regulator voltage to the VDDCORE.

[7] When performing any OTP read/write function, the VDDCORE voltage must be set to 1.0 V or higher when LDO_ENABLE is externally

tied high or low.

[8] Low voltage operating range is for applications using the RT600 at VDDCORE voltages between 0.7 V to 0.9 V. So for example, if an

application is using VDDCORE = 0.7 V and 0.9 V, max frequencies defined for the low voltage operating range must be used. Full

voltage operating range is for applications using the RT600 at VDDCORE voltages between 0.7 V to 1.13 V. So for example, if an

application is using VDDCORE = 0.7 V and 1.13 V, max frequencies defined for the full voltage operating range must be used. Low

voltage range provides higher operating speeds when compared to full voltage operating range. After Boot-up, application must select

either low voltage range or full voltage range. An application cannot switch between low voltage range and full voltage range mode.

VDDCORE [3] Low voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(DSP Max Freq = 115 MHz, FBB).

0.7 - 1.155 V

Active Mode

(DSP Max Freq = 260 MHz, FBB).

0.8 - 1.155 V

Active Mode

(DSP Max Freq = 375 MHz, FBB).

0.9 - 1.155 V

Full voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(DSP Max Freq = 70 MHz, FBB).

0.7 - 1.155 V

Active Mode

(DSP Max Freq = 195 MHz, FBB).

0.8 - 1.155 V

Active Mode

(DSP Max Freq = 300 MHz, FBB).

0.9 - 1.155 V

Active Mode

(DSP Max Freq = 480 MHz, FBB).

1.0 - 1.155 V

Active Mode

(DSP Max Freq = 600 MHz, FBB).

1.13 - 1.155 V

VDDIO_0/1/2 Supply voltage for GPIO rail. 1.71 - 3.6 V

VDDA_1V8 1.8 V analog supply voltage for ADC and

comparator.

1.71 - 1.89 V

VDDA_BIAS [2] Bias for ADC and comparator. 1.71 - 3.6 V

VREFP ADC positive reference voltage. 1.71 - 1.89 V

USB1_VDD3V3 USB1 analog 3.3 V supply. 3.0 -3.6V

Table 20. General operating conditions …continued

Tamb =0



C to +85



C, unless otherwise specified.

Symbol Parameter Conditions Min Typ[1] Max Unit

VDD1VB_1 7

Product data sheet Rev. 1.7 — 20 January 2021 94 of 163

NXP Semiconductors RT600

Dual-core microcontroller with 32-bit Cortex-M33 and Xtensa HiFi4

Audio DSP CPUs

Table 21. General operating conditions

Tamb =-20



C to +85



C, unless otherwise specified.

Symbol Parameter Conditions Min Typ[1] Max Unit

fclk CPU (Cortex-M33) clock frequency. - - 300 MHz

CPU (Cortex-M33) clock frequency For USB high-speed device and

host operations

90 - 300 MHz

CPU (Cortex-M33) clock frequency. For USB full-speed device and

host operations

12 - 300 MHz

fclk DSP clock frequency - - 580 MHz

VDD_AO1V8 Supply 1.8 V supply for “always on”

features.

1.71 -1.89V

VDD1V8 1.8 V supply voltage for on-chip analog

functions other than the ADC and

comparator.

1.71 -1.89V

VDD1V8_1 [4] 1.8 V supply voltage for OTP. 1.71 -1.89V

VDDCORE

[3][5][6][7]

Power supply for core logic. On-chip

regulator not used. Power supplied by

an off-chip power management IC

(PMIC).

Retention Mode 0.7 -1.155V

Low voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(M33 Max Freq = 60 MHz, FBB).

0.7 -1.155V

Active Mode

(M33 Max Freq = 140 MHz, FBB).

0.8 -1.155V

Active Mode

(M33 Max Freq = 215 MHz, FBB).

0.9 - 1.155 V

Full voltage operating range.

SDK Power Library version = 0x020300,

SDK version 2.8.3 and later. [8]

Active Mode

(M33 Max Freq = 50 MHz, FBB).

0.7 -1.155V

Active Mode

(M33 Max Freq = 135 MHz, FBB).

0.8 -1.155V

Active Mode

(M33 Max Freq = 200 MHz, FBB).

0.9 - 1.155 V

Active Mode

(M33 Max Freq = 270 MHz, FBB).

1.0 - 1.155 V

Active Mode

(M33 Max Freq = 300 MHz, FBB).

1.13 - 1.155 V

VDDA_B|AS 7

Product data sheet Rev. 1.7 — 20 January 2021 95 of 163
